AIR PRODUCTS in Control SERIES SMOKE DETECTORS APPLICATION SM 501 Series Duct Smoke Detector provides early detection smoke and products of combustion present in air moving through ducts in Commercial Industrial and Residential applications unit is designed to prevent the re circulation or spread of smoke by handling systems fans and blowers Complete systems may be shut in the event of smoke detection SM 501 model will operate on any one of four input voltages 115VAC 24VAC or 24VDC The SM 501 allows up to 30 to be interconnected for many common functions DESCRIPTION our history of building innovative and reliable products SM 501 is housed in our popular traditional compact housing The provides two sets of 10 Amp form alarm contacts along one set of 10 Amp form trouble contacts for monitoring removal and supply voltage failure green pilot and red alarm visual indicators provided on the front the SM 501 signal the operating status of the device The green pilot will be extinguished when the detector head is removed or power is A manual test reset switch is located next to the visual indicators LISTED ACCEPTED SM 501 has been specially designed to allow linkage of common detector functions for up to 30 detectors units may be wired to use a common test reset function and to alarm when a single unit alarms Also up to units with signaling devices may be interconnected to operate with a single alarm SM 501 is designed and built to meet all local code requirements as well as the NFPA and ICC standards HVAC supply and return duct smoke detectors Output terminals are provided for remote accessories as horns strobes remote status indicators and test reset key switches or push buttons SM 501 is available with either ionization or photoelectric detector heads which are interchangeable Air sam is accomplished via two rear loading tubes which protrude into the duct An exhaust tube of one standard 7.0 is supplied in the installation kit with the duct smoke unit Once the duct width has been determined air intake sampling tube must be ordered Sampling tubes are supplied in standard lengths 1.0 2.5 5.0 10.0 and are cut to size to fit the duct Mounting the duct smoke detector is accomplished by the use of a and four sheet metal screws as provided Mounting can be achieved without the removal of the clear cover is secured by four captive screws Operating voltages 230VAC 115VAC 24VAC 24VDC Both models listed for high temperature applications Interconnect up to 30 units for common functions UL CUL CSFM and MEA Listed Compact Size Two sets of 10A form alarm contacts One set of 10A form trouble contacts Rugged steel back box with clear cover Compatible with the WP 1 weatherproof enclosure Easy retro fit upgrade of existing RW Series detectors Clear cover fitted with 4 captive screws Large terminal connection screws Interchangeable photoelectric or Easy mounting without cover removal Advanced detector head design yields internal dust filtering with no additional screens or filters to clean Over 15 remote accessories available heads By Products and Controls a Brand of Apollo America Corporate Drive Hills MI 48326 332 3900 Phone 332 2241 Toll free 332 8807 Fax RED RED RED RED RED RED BLK BLK BLK BLK BLK BLK mA mA mA mA mA mA mA mA tube for 12 or less duct width tube for 6 to 2.5 duct width tube for 2.5 to 5.0 duct width tube for 5.0 to 10.0 duct width 230VAC 115VAC 24VAC 24VDC 230VAC 115VAC 24VAC 24VDC or 55000 225APO or 55000 328APO Tube Sectional sampling tube kit fits up to 90 duct width remote accessories WP 1 weatherproof TG 1000 aerosol test gas and T PB power supplies available from Apollo America SPECIFICATIONS NUMBER HEAD MODEL NUMBER TUBES REQUIREMENTS without accessories Standby Alarm CONTACT RATING Alarm Contacts load 2 sets form rated at 10 Amps 115VAC Trouble Contacts load 1 set form rated at 10 Amps 115VAC VELOCITY to 4,000 ft min TEMPERATURE RH 32 86 Non Condensing Non Freezing or stranded 12 to 22 AWG terminals CUL Listed UL268A UROX UROX7 File S2829 Listed 3240 1004 108 Accepted 73 92 E VOL 26 Steel backbox clear plastic cover Makrolon 94V 0 paint 1 8 L x 7 1 4 W x 2 1 4 H NET WT 1 2 lbs SM 501 N Ionization Americium 241 0.9 Micro Curie ELEMENT not expose to corrosive atmospheres exhaust tube sampling tube end cap mounting template mounting hardware included ARCHITECTS SPECIFICATIONS Air duct smoke detectors shall be Air Products and Controls Inc SM 501 Series For Ionization detectors the model number is SM 501 N For photoelectric detectors the model number is SM 501 P The detectors shall be listed by Underwriters Laboratories per UL 268A The detectors shall operate at air velocities from 500 feet per minute to 4,000 feet per minute and at temperatures of no greater than 140 60 The duct detector housings shall be of metal construction and complete mechanical installation may be performed without removal of detector cover Visual indication of alarm and power must be provided on the detector front A manual reset switch shall be located on front of the device Detector head shall not require additional filters or screens which must be maintained The housing shall contain a detector base which will accept photoelectric or ionization detector heads Terminal connections shall be of the screw type and be a minimum of 6 screw 12 to 22 AWG compatible Terminals shall be provided for Capability for interconnection of up to 30 units shall be provided for common functions pilot remote alarm indications strobe horn and remote test reset switch All wiring must comply with local codes and regulations to 158 0 to 70 to 140 0 to 60 The information contained in this document is intended only as a summary and is subject to change without notice The products described have specific in documentation which covers various technical approval code limitation and liability information Copies of this documentation along with any general warning and limitation documents which also contain important information are provided with the product and are also available from Apollo America The contained in all of these documents should be considered before specifying or using the products Any example applications shown are subject to the most enforced local national codes standards approvals certifications and or the authority having jurisdiction All of these resources as well as the specific manu of any shown or mentioned related equipment should be consulted prior to any implementation For further information or assistance concerning the products contact America Apollo America reserves the right to change any and all documentation without notice Apollo America 2013 D051230
