Potter SSX-52 Series 120dB Durable Siren or Siren Strobe

File Preview
File Preview
Click below to download for free

File Data

Name potter-ssx-52-series-120db-durable-siren-or-siren-strobe-9541627803.pdf
Type PDF
Size 807.63 KB

Text Preview

A Brand SERIES SIREN SIREN STROBE Self Contained Indoor Outdoor Siren and Siren Strobe Sturdy aluminum back plate Strong polycarbonate housing Dual tamper protection 115dB sound output Warble sound output Mounts directly to wall or 4 square back box Strobe consists of colored mirror and lens Available strobe colors Amber blue clear red SSX 52 is a durable indoor outdoor self contained siren The full featured siren consists of a single tone that delivers a warble sound 115dB 1 meter output siren driver and a dual action reed plunger for cover and rear protection The SSX 52 is provided with a strong housing and a sturdy aluminum back plate to prevent warping and cracking The SSX 52 comes completely assembled and ready installation SSX 52S Siren Strobe is also available It includes all the great SSX 52 features with the addition of a colored strobe The strobe uses a mirror and lens to ensure that the color can be easily distinguished and is available in amber blue clear or red SSX 52 52S excels in noisy areas such as warehouses loading docks print shops busy production floors or for indoor outdoor applications high quality and high output warning is required inches mm Dimensions inch mm case of the SSX 52S Switch 111 85.8 Holes 147 SSX 5S SSX 52 Voltage Specifications Specifications Candela on Axis Rate Contact 12 VDC 14.4 VDC mA mA VDC 14.4 VDC Min Min Min Min 100 12V DC to 149 to 65 Electric Signal Co LLC St Louis MO Cust Service 866 240 1870 Tech Support 866 956 1211 Canada 888 882 1833 www pottersignal com IN USA MKT 8880143 REV C 11 20 1 OF 1
