Radionics - D7024 Reference Guide Fire Control

Reference Guide the Control Communicator Inc 1800 Abbott Street CA 93901 U S A Service 800 538 5807 1997 Radionics Inc Salinas CA U S A All rights reserved The Radionics logo is a registered trademark of Radionics Inc Salinas CA U S A Reference Guide P N 31499B of Contents Compliance Notice Phone Connection to Users Overview System Overview Specifications Programming Menu Tree PROG 0 Menu Tree CMND TEST HISTORY DRILL Installation Guide for U L Listed Systems 24 D7024 U L Listings Installation Considerations Programming the D7024 Reversing Modules A Abbreviations on Panel Dis B Defaults for PROG 0 Enclosure Housing Temperature Power Outputs Zones Initiating Circuits Keypads Communicator Users Lightning Protection Backup Battery Calculation Standby Current Load Enclosure Installation Install the Enclosure Install the Control Communicator Control Terminal Wiring System Worksheet Operating Guide Understanding the Built in Keypad Understanding the D7033 Keypad System Operation Modes of System Operation Point Zone Mapping Fire Silence Reset System Trouble Fire Safety If Installed in Family Residences Having and Practicing an Escape Installation Considerations Personal Identification Numbers Error Displays Testing Remote Program Dial out and Answer How to Program ALPHA Programming Format Programming 4 2 BFSK SIA 2 1997 Radionics Inc D7024 Reference Guide you experience trouble with this equipment please the manufacturer for information on obtaining or repairs telephone company may ask that you disconnect equipment from the network until the problem has corrected or until you are sure that the equip is not malfunctioning The repairs to this must be made by the manufacturer and the user guard against accidental disconnection there is room to mount the Telco jack to the inside of Control cabinet operation of this Control may also be affected if such as accidents or acts of God cause an in telephone service Industry Canada label identifies certified equip This certification means that the equipment certain telecommunications network protective and safety requirements Industry does not guarantee the equipment will to the user satisfaction installing this equipment users should ensure it is permissible to be connected to the facilities of local telecommunications company The equip must also be installed using an acceptable of connection The customer should be aware compliance with the above conditions may not degradation of service in some situations to certified equipment should be made by an Canadian maintenance facility designated the supplier Any repairs or alterations made by the to this equipment or equipment malfunctions give the telecommunications company cause to the user to disconnect the equipment should ensure for their own protection that the ground connections of the power utility lines and internal metallic water pipe if present are connected together Users should not attempt to make such themselves but should contact the electric inspection authority or electrician appropriate Compliance Notice Phone Connection to Users equipment has been tested and found to comply the limits for a Class A digital device pursuant to 15 of the FCC Rules These limits are designed provide reasonable protection against harmful in a residential installation This equip generates uses and can radiate radio frequency and if not installed and used in accordance the instructions may cause harmful interference radio communications However there is no that interference will not occur in a particu installation If this equipment does cause harmful to radio or television reception which can determined by turning the equipment off and on user is encouraged to try to correct the interfer by one or more of the following measures Re orient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment into an outlet on a circuit from that to which the receiver is con Consult the dealer or an experienced radio TV for help control complies with Part 68 of the FCC rules the inside of the enclosure is a label that contains other information the FCC Registration and the Ringer Equivalence Number REN this equipment You must upon request provide information to your local telephone company REN is useful to determine the quantity of that may be connected to your telephone line still have all of those devices ring when your number is called In most but not all the sum of the REN of all devices connected one line should not exceed five 5.0 To be certain the number of devices that you may connect to line you may want to contact your local tele company to determine the max REN for your calling area equipment may not be used on coin service by the telephone company This control not be connected to party lines this equipment cause harm to the telephone the telephone company may discontinue service temporarily If possible they will notify in advance But if advanced notice isn practical will be notified as soon as possible You will be of your right to file a complaint with the FCC telephone company may make changes in its equipment operations or procedures that affect the proper functioning of your equipment they do you will be notified in advance to give you opportunity to maintain uninterrupted telephone D7024 Reference Guide 1997 Radionics Inc Page 3 Overview System Overview Outputs D7024 Control Communicator is a fully integrated fire alarm system It can support 4 input expandable to 8 and 16 individual users The panel has a built in LCD keypad however up 4 additional keypads may be used to provide user with the system and programming access for installer The D7024 also includes the following Built in Dual line Communicator Menu Driven Keypad Programming Freely Programmable Alpha Display 100 Event History Buffer 16 User Codes U L Listed C S F M Approved Specifications Enclosure Housing standard enclosure is manufactured from 18 cold rolled steel and measures 15 in Wide by in High by 4.25 in Deep 38.1 cm Wide by cm High by 10.8 cm Deep A keyed lock is and the LEDs and display are visible the door Temperature Storage and Operating Temperature to 120 0 to 49 Power Input Power V 60 Hz 1.5 A max 20 A fused Notification Appliance Circuit Power VDC nominal unfiltered special application up to 2.5 A capacity but limited by overall A capacity Refer to Technogram P N 34950B compatible devices Auxiliary Power VDC nominal unfiltered special application to Technogram P N 34950B Initiating Circuit Smoke Power VDC nominal to Technogram P N 34445B Option Bus Power V 5 500 mA Optional Standby Batteries 12 V in series 7 40 AH 2 on board notification circuits NAC 1 and NAC 2 are 24 V outputs for notification devices with to 2.5 A capacity but limited by overall 4.0 A on each circuit Wired for standard Class B operation Local Relays The main panel includes two Form relays The relay contacts are rated at 6 A VDC No transient suppression or overcurrent are performed on the contacts of these The default selection for the relays is to general alarm and general system By programming them to one or two of zone numbers described for point zone they can be programmed to activate on variety of
