Cerberus Pyrotronics AA-30U Output Module 3129

System 3 Output Modules AND ARCHITECT SPECIFICATIONS AND ARCHITECT SPECIFICATIONS AA 30U AA 30U AE 30U AE 30U Styles Y or Z Circuit LED Trouble Placement AC or DC Audibles ULC NYMEA FM and City of Approved AA 30U Audible Alarm Extender Module has been for use with the System 3 control panel and meets requirements of NFPA 72 Style Class module provides a four wire circuit for operating parallel connected 24 Vdc notification appliances circuit capacity is typically 20 vibrating dc bells 10 dc or strobes However depending on the current of the connected devices additional bells or strobes can be added providing the total circuit does not exceed 1.5 amperes of the module is caused by a high going input from a system control module Dual input activation are provided for programming or sequencing its Model AA 30U contains a yellow LED indicator the face of the module which indicates an open or loop condition This is operative at all times except the system is in alarm Model AA 30U is placement supervised providing a trouble signal upon removal from the system Power the alarm circuit is fused within the module The fused requires an end of line resistor valued at 5.6 K ohms 5 watts A Alarm Module Audibles Visuals B Alarm Module or DC Audibles Visuals AE 30U Audible Alarm Extender Module has been for use with the System 3 control panel and meets requirements of NFPA 72 Style Class module provides a two wire circuit for operating polariz parallel connected 24 Vdc or 120 Vac notification app The circuit capacity varies depending on device and rating The total circuit load must not exceed 1.5 of the module is caused by a high going input from a system control module Dual input activation are provided for programming or sequencing its Model AE 30U contains a yellow LED indicator the face of the module which indicates an open or condition This is operative at all times except when system is in alarm Model AE 30U is placement supervised providing a trouble signal upon removal from the system The wire circuit which is fused requires an end of line valued at 5.6K ohms and rated at 5 watts for DC and 5 watts for AC devices NUMBER and Architect Specifications and Architect Specifications Style systems a notification appliance circuit for operating 24 Vdc polarized audible alarm devices shall be provided a Cerberus Pyrotronics Audible Alarm Class Module Model AA 30U This module shall be system inter connected by ten pin plug and harness assembly and shall be operable with the main control panel receipt of a high going DC actuating signal the solid state circuitry shall supply operating power for vibrating 24 Vdc 24 Vdc horns or strobes The maximum output current shall be limited to 1.5 amperes The audible devices shall a four wire fused supervised circuit module shall contain a yellow LED indicator lamp to indicate an open or shorted alarm line when the system is in the condition The LED shall be lamp tested from the main control panel Model AA 30U shall be placement supervised and shall be Underwriters Laboratories Inc listed of Line Device Power Note 1 Note 2 Ohms max Line Resistance Notification Circuit Wires Notification See Note 3 Z Class A Connected Polarized Appliances Shown in Supervisory Condition 5mA or 120VAC 1.5 Max NOTIFICATION APPLIANCES 1 strobe When Style Z Class A type notification appliance circuit configuration is used 24 VDC appliances are required Use EOL device Model EL 31 and DC program plug Model in P2 Notification appliance circuits may be activated from the silenceable system alarm output terminal 36 of CP 35 or from the non silenceable system alarm output signal terminal 42 CP 35 When other alarm signals such as coding or time delay limit are required see individual connection diagrams Refer to the BI 35 Installation Instructions P N 315 086257 for detailed wiring information using the AA 30U in conjunction with the BI 35 module Use only the compatible polarized notification appliances in the following table To use power limited wiring to NFPA 70 NEC Article 760 the notification appliance circuits 3 4 7 and 8 must use the PLM 35 module Refer to Instructions P N 315 093495 Strobes 8 Tone Horns Slow Whoop and Architect Specifications and Architect Specifications Style systems a notification appliance circuit for operating 120 Vac or 24 Vdc polarized audible alarm devices shall provided by a Cerberus Pyrotronics Audible Alarm Class Module Model AE 30U This module shall be system by a ten pin plug and harness assembly and shall be operable with the main control panel receipt of a high going DC actuating signal the solid state circuitry shall supply operating power for AC bells or AC For DC devices it shall power vibrating DC bells DC horns or strobes The maximum output current shall be limited 1.5 amperes The audible devices shall require a four wire fused supervised circuit module shall contain a yellow LED indicator lamp to indicate an open or shorted alarm line when the system is in the condition The LED shall be lamp tested from the main control panel Model AE 30U shall be placement supervised and shall be Underwriters Laboratories Inc listed Y Class B Appli Shown in 24VDC 5mA 24VDC or Max to the BI 35 Instructions P 315 086257 for detailed information when the AE 30U in
