Cerberus Pyrotronics CMI-300 CXL MXL Interface Module 5014

ENGINEER AND ARCHITECT SPECIFICATIONS Interface Module Interface for MXL CXL Provides Remote Monitoring and Control Built in Modem 8 Miles with Twisted Pair Wire Fiber Optic Interface Unlimited Distance with Data Grade Lines Plugs into MOM 2 MOM 4 Cardcage Slot Allows Bi Directional Communication Alarm and Trouble Monitoring Diagnostic Report Generation ULC Listed NYMEA CSFM City of Chicago Approved CMI 300 is an MXL option module which provides communication between an MXL and a CXL The CMI 300 plugs into any available 1 2 slot on MOM 2 MOM 4 cardcage This interface board trans signals from the MXL network to CXL compatible signals CMI 300 allows alarm and trouble information to be from the MXL to the CXL as well as allowing execution of commands from the CXL to the MXL can be wired in either a Style 4 or Style 6 configuration 18 AWG 2 conductor cable with a distance limitation approximately 8 miles It can also be used with dedi data grade conditioned telco lease lines 600 Ohms 2 wire full duplex with no distance limitation to CXL communication is also possible via fiber optic Note Dedicated data grade phone lines are amplified via telephone system equipment lines are supervised by the CXL and therefore pass through switching stations on general voice lines communications between the MXL and CXL are via the CMI 300 equipment is approved for operation over the tem range of 0 and 49 and Architect Specifications communication between an MXL and a CXL shall be provided by a CMI 300 MXL option The CMI 300 shall plug into any available 1 2 slot an MOM 2 MOM 4 cardcage This interface board shall signals from the MXL network to Cerberus CXL system compatible modem signals CMI 300 shall allow alarm and trouble information to transmitted from the MXL to the CXL as well as allowing execution of commands from the CXL to the MXL system report generation such as device sensitivity It shall be capable of either a Style 4 or Style 6 configuration using 18 AWG 2 conductor cable with distance limitation of approximately 8 miles It shall also capable of use with dedicated data grade conditioned lease lines 600 Ohms balanced 2 wire full duplex no distance limitation MXL to CXL communication is possible on fiber optic cable at distances up to 10,000 between fiber optic interface modules communication between the MXL and the CXL shall be supervised via the CMI 300 NUMBER Data Rating or Alarm Battery Current 30mA max Data MOM 2 MOM 4 SLOT Wiring P N 140 820366 Use 2 wire copper cable 105 300V 18AWG solid or stranded Do use more than seven strands The recommended cable is Belden or its equivalent All wiring must conform to local codes and to the authority having over the installation Pyrotronics Ridgedale Ave Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1996 sheet dated 7 95
