CP 2ER Control Panel ENGINEER AND ARCHITECT SPECIFICATIONS CP 2ER CP 2ER Class A or B Options Cross Zoned Detection Circuits Limited Option on Notification Circuits LED Indicating Various Normal Off Normal Conditions Discharge Delay Time Selection or 60 Hour Battery Back Up Manual or Automatic Release Release Disconnect Switch as Complying with Either 72 12A 13 or 2001 CSFM and NYMEA Approval NFPA Style D NFPA Style b Cerberus Pyrotronics Control Model CP 2ER is a two local control unit which meets the requirements of NFPA or a two zone releasing device panel approved in accor with NFPA 72 12A 13 and 2001 for cross zone When the CP 2ER Control Panel is used as a device two Class A or Class B detection circuits arranged so that both zones must be activated in order to the agent automatically into the protected area Control Panel provides for the external connection of manual discharge switches for releasing of agent well as several other supervised input and output func Essentially every supervised feature has its own fault indicator for ease of troubleshooting the should a fault occur through the front cover are the usual visual for power system alarm and system trouble as as several additional specific function indicators Within Control Panel are a fire alarm RESET LAMP TEST switch ALARM SILENCE switch a SUPERVISORY SILENCE a TROUBLE SILENCE switch and a RELEASE DIS switch The separate visual fault indicators are within the panel for all supervised features of power limited Module PLM 35 allows power wiring of alarm indicating circuits This permits alarm wiring to be run in same conduit with initiating device or with other power limited circuit wiring Isolated relay are provided for System alarm DPDT System SPDT Predischarge discharge SPDT and open Automatic Discharge Operation single zone alarm condition results in Alarm lock in of that zone Visual alarm indication of that zone General alarm condition of panel which includes Change of state of fire alarm relay contacts General alarm audible circuit activated activation of both zones the discharge delay sequence The discharge delay period may be preselected by Rotary Switch the discharge delay period begins both zones alarmed the general alarm audible circuit is de energized the relay contacts TB3 terminals 10 through 14 state See Option No 4 The predischarge audible NUMBER device service in accordance with NFPA 72 Local fire code 12A Releasing of Halon 1301 13 Preaction 2001 Releasing of clean agent It shall provide A NFPA Style D and B NFPA Style B options and 10 selectable discharge delay up to 45 seconds shall provide the following abort options Abort operational only if only one detection zone has Full discharge delay follows release of abort after both zones have activated Abort operational anytime before discharge delay has Continuation of unexpired discharge delay release of abort switch Same as 2 except full discharge delay follows release abort switch shall provide the following manual discharge options Operation of manual discharge switch results in delay prior to discharge Operation of manual discharge switch results in imme discharge Use With Alarm System control panel for the manual or automatic fire alarm shall be Cerberus Pyrotronics Model CP 2ER It be FM approved and UL listed as a local control unit accordance with NFPA 72 12A 13 and 2001 It shall A NFPA Style D and B NFPA B options on two initiating device circuits Information 120 VAC 102 132 50 60 Hz 3 wire 2 amp max 2 with ground Information When ordering specify whether batteries shall be 24 60 hour standby capacity No Description Panel Hr Battery Pack for CP 2ER 5AH Hr Battery Pack for CP 2ER 10AH lbs kg lbs kg lbs kg Excluding Batteries Batteries must be ordered separately for CP 2ER pc BP 24 or 1 pc BP 60 must be ordered for battery backup along with its associated visual indicator is cycled at a Hz rate with a 50 duty cycle during the selected dis delay period At the conclusion of the discharge delay the agent release circuit is energized for approxi 1 minute while the discharge audible is energized in a condition until either it is silenced or the panel is to a non alarm condition Manual Discharge Operation Selection Operation of the MANUAL DISCHARGE switch results in a delay period as selected before actual dis begins provided the delay selected is 30 seconds less When the discharge delay selector is set for more 30 seconds the MANUAL DISCHARGE switch opera gives a 30 second delay period maximum Operation of the MANUAL DISCHARGE switch results in discharge regardless of delay period selected Abort Station Operation Selection When used abort function is operational if only one but two of the detection device cicuits has activated of the ABORT switch after both detection circuits activated results in the regular preselected discharge period as selected Discharge may be aborted at any time before selected delay period has expired and disharge has Release of the ABORT switch after both detection have activated results in continuation of the discharge delay period as selected Discharge may be aborted at any time before selected dis delay period has expired Release of the ABORT after both detection circuits have activated results in complete discharge delay period as selected Predischarge Discharge Delay Operation Selection Relay contacts change state on any of the following con without any delay period Both detection circuits have activated MANUAL DISCHARGE switch has been operated Normally open MANIFOLD DISCHARGE monitor switch closed Relay contacts change state at conclusion of selected delay period when operated by activating both circuits or by activating manual discharge The agent release disconnect switch is a normally closed switch in the release circuit Moving the switch to disconnect position causes a Discharge Trouble and prevents a discharge This switch is used servicing of the system as a safeguard against discharge NFPA 72 12A 13 or 2001 shipped from the factory the CP 2ER is arranged to meet NFPA 72 requirements that is an alarm in either of the initiating zones will cause general alarm to sound Once general alarm is silenced an alarm in the other initiating will cause the general alarm to sound again The of the service selection plug will automatically the alarm program to comply with NFPA 12A 13 and requirements and Architect Specifications Use With Extinguishing System control panel for release of the extinguishing system be a Cerberus Pyrotronics Model CP 2ER It shall be CSFM and NYMEA approved and UL listed for releas INDICATORS Indicators Externally Visible POWER Steady on indicates main power is normal Flashing on off indicates panel is operating from the backup battery supply System TROUBLE Indicates a general system trouble System SUPERVISORY Indicates a general system supervisory ALARM ZONE 1 ALARM ZONE 2 Predischarge DISCHARGE alarm operates in flashing mode upon cross zone 1 and Zone 2 activation condition until preselected time delay has expired in steady mode upon and following actual discharge Audible ALARM SILENCED indicates that either the general alarm audible device or predischarge discharge audible device circuit has been silenced Indicators Internally Visible Must open panel door to be viewed BATTERY FAULT indicates high low or open battery fault condition or open battery circuit GROUND FAULT Abort station circuit fault ABORT TROUBLE Manual release station circuit fault MANUAL DISCHARGE TROUBLE Release circuit fault AGENT DISCHARGE TROUBLE Zone 1 initiation circuit fault ZONE 1 TROUBLE Zone 2 initiation circuit fault ZONE 2 TROUBLE General alarm audible circuit fault GENERAL ALARM TROUBL
