Cerberus Pyrotronics CZM-4 Conventional Zone Module 5003

ENGINEER AND ARCHITECT SPECIFICATIONS Zone Module Four Conventional Initiating Device Circuits Supports the Use of Two Wire Photo or Ion Detectors Per Circuit Beam Detector Limit 1 Per Zone Shorting Devices Relay Bases Bases Indicator Lamps Class A Style D Class B Style B On Board Microprocessor 32 Character Custom Alphanumeric Message Zone Optional Alarm Verification by Zone Walk Test by Zone Circuits Power Limited per NEC 760 Listed ULC Listed FM CSFM NYMEA and City of Chicago Approved Conventional Zone Module CZM 4 is used with the MXL provide four Class A Style D or Class B Style B conven initiating device circuits Each circuit can monitor up 30 Cerberus Pyrotronics two wire photoelectric or smoke detectors and an unlimited number of open contact devices Projected Beam Detectors also be used The CZM 4 circuits will support the use Detector Relay Bases Audible Bases and remote indica lamps Activation of any device on a circuit will initiate a alarm condition resulting in the operation of pro functions Any circuit in the alarm or trouble will be identified by a user specified 32 character message displayed on the MXL LCD annun of the CZM 4 circuits are designed to function in a mode during failure of the MXL main or the loss of the system communication network in the mode the CZM 4 is still capable of both alarm and trouble conditions and activating outputs or all of the CZM 4 circuits can be programmed to with the Verification feature This feature the automatic verification of alarm conditions caused smoke detectors in order to prevent nuisance alarms CZM 4 module plugs into one full slot in the MOM 2 or expansion card cage Up to two CZM 4 modules be plugged into a MOM 4 card cage and Architect Specifica two wire initiating devices such as smoke heat detectors manual stations and sprinkler switches shall be connected to circuits provided the Cerberus Pyrotronics Conventional Zone Module plugged into the MOM 2 or MOM 4 expansion card Each zone shall support the use of up to 30 Cerberus two wire smoke detectors and an unlimited of UL listed shorting devices Zones shall also the use of compatible Projected Beam Detectors Relays Audible Bases and Remote Indicator Each CZM 4 shall provide four independent Class Style D or Class B Style B initiating device circuits conventional zone module shall contain an on board Initiating device circuits shall be capable a local mode of operation during failure of system processor or loss of the communication During main system processor failure or loss of NUMBER Diagram o t e s Circuits can be class A or class B All circuits are power limited per NEC 760 All circuits are supervised Do not connect more than one PBA 1191 to each zone Refer to the PBA 1191 315 094912 Do not mix smoke detectors with the PBA 1191 Maximum PBA 1191 requires Rev 3 or higher of CZM 4 software OHMs circuit Data network initiating device circuits shall be of reporting both alarm and trouble conditions and be capable of activating local alarm indicating order to minimize standby battery drain the end of line devices should be non current drawing 50VDC capacitors With beam detectors an EOL resistor must used CZM 4 shall plug into one full slot in the MOM 2 or expansion card cage It shall interface with the or MOM 4 using gold plated edge connectors Up two CZM 4 modules may be plugged into one MOM 4 circuit on the CZM 4 shall be assigned a 32 character alphanumeric message which will be displayed on MXL LCD annunciator when any device attached to that is activated or when any wiring fault open or shorted wiring exists on that circuit Specifications CONNECTIONS Initiating device circuits range current EOL current Initiating devices per zone VDC max max resistor EOL max per zone to 30 detectors any combination of those in No 3 Up to five waterflow switches may be used Any of direct shorting devices may be used Wiring be Style D Class A or Style B Class B The UL identifiers for compatibility are the same as the names specified below Compatible Cerberus detectors are Instructions 315 081943 315 081943 315 085257 315 085257 315 086590 315 086591 315 086592 315 086441 315 086545 315 094912 All circuits are power limited to NFPA 70 per NEC 760 detector or group of detectors must use a two wire of at least 18 AWG thermoplastic fixture wire in conduit or 18 AWG limited energy shielded without conduit if permitted by local building Total circuit resistance must not exceed 70 ohms 40 if relay bases are used Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1997 sheet dated 9
