System 3 Control Module AND ARCHITECT SPECIFICATIONS HC 35 HC 35 Module Module Cross Zone Automatic Release Discharge Delay Timing Options Supervises Cylinder Pressure Confirms Agent Discharge Automatic or Manual Listed FM CSFM NYMEA Approved Fire Extinguishing System Control Module HC 35 is to effect either manually or automatically the dis of Halon halogenated fire extinguishing agent or extinguishing agents as covered by NFPA 12 12A It Underwriters Laboratories Inc and U L Canada listed Factory Mutual and California State Fire Marshal assure continuous operation of the extinguishing the HC 35 utilizes the 24 or 60 hr battery back up by the System 3 control panel HC 35 connects to 2 separate automatic initiating which are cross zoned therefore requiring both to be in order to activate agent release shorting contact device circuit which accommodates station controls series MH 501 517C is also for immediate or selectable time delayed agent HC 35 also provides for utilization of the Cerberus AW 1 abort station When the AW 1 is used the will provide various selectable system abort timing operation a supervised agent release circuit of up to 4 series connected solenoids auto releases the extinguishing agent from the con This circuit is reset from the CP 35 control panel 3 red alarm LED are provided to identify means confirmation of agent release as listed below Discharge LED flashes during selectable time delay then goes steady when solenoids are ener Manual Station LED lights when manual release is activated Manifold Discharge LED lights when pressure is in the discharging piping Separate pressure is required 4 yellow trouble LED are provided to indicate in Release solenoid circuit The Manual Station release MH 501 517C circuit The abort station AW 1 circuit Low cylinder pressure separate cylinder pressure required LED can be lamp tested from the system control The HC 35 module which occupies four 4 module is placement supervised and provides a system signal when removed NUMBER module is also fitted with a manually operated Discon Switch which disables the release circuit during test When placed in the disconnect position the panel goes into the system trouble mode and the trouble LED identified Circuit is illumi various timing options are listed as follows and set by switches Discharge Delay 0 60 seconds in 10 second increments Abort Delay 1 Operational only if activated before second is in alarm Release of the abort switch after both are in alarm will result in the regular preselected Delay time 2 Actuated at any time before the preselected Delay time expires the release of the abort after both zones are in alarm will result in a delay 10 seconds before the actual discharge 3 Actuated at any time before the preselected Delay time expires the release of the abort after both zones are in alarm will result in a con of the unexpired preselected Discharge Delay before actual discharge begins In options 1 and 3 the maximum delay period by U L is 10 seconds Manual Station Release 1 Actuation of a manual station release results a discharge delay period equal to the period pre for the Discharge Delay provided the delay was 30 seconds or less Manual station activa has a maximum discharge delay of 30 seconds 2 Actuation of a manual station release results an immediate discharge regardless of the preselected delay period Requirement 53mA Diagram for max of 64 seconds followed by 106mA and Architect Specifications extinguishing system automatic or manual release shall be a Cerberus Pyrotronics Model HC 35 This shall be system interconnected by a ten pin plug harness assembly and shall be operated with and by the main control panel HC 35 shall provide a supervised agent release circuit of operating up to four 4 series connected 6VDC 1.6 A each The unit shall operate on receipt of two 2 independent actuating inputs from zoned detection circuits or by the actuation of any station release supervised Disconnect Switch shall be provided to the release circuit for system test purposes shall cause identified trouble indications on module as well as system trouble 3 red alarm LED shall be provided to indicate Predischarge flashing and discharge steady Manual Station release actuation Confirmation of agent release pressure switch sensed 4 yellow trouble LED shall be provided to indicate Fault in the Manual Station release circuit Fault in the Abort circuit Fault in the solenoid release circuit Low cylinder pressure pressure switch sensed module shall provide various timing options in each of following listed operations Automatic actuation Discharge Delay Abort Switch release Discharge Delay Manual Station release Discharge Delay second max module shall be U L and U L C listed and approved Factory Mutual California State Fire Marshal and Information Wt Extinguishing System Module lb 1.8 kg installation Instructions P N 315 085659 The use of other than Cerberus Pyrotronics detectors and bases with Cerberus equipment will be considered a misapplication of Cerberus Pyrotronics and as such void all warranties either expressed or implied with regard to loss liabilities and or service problems Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1996 sheet dated 11 91
