Cerberus Pyrotronics ILT-1 Intelligent Thermal Detector 6167

ILT Series Thermal Detectors for IXL MXL and XL3 Control Thermal Detectors for IXL MXL and XL3 Control AND ARCHITECT SPECIFICATIONS AND ARCHITECT SPECIFICATIONS Microprocessor Based Design Innovative Technology Provides High Speed Fault System Detector Communications Alarm Indicator LED Two Wire Operation Compatible with SensorLINK Model FPI 32 Field Listed ULC Listed CSFM and NYMEA Approved and FM Pending Pyrotronics ILT 1 intelligent thermal detectors an advanced method of detection address and supervision combined with sophisti control panel communication The ILT 1 detectors supplied with a 135 rate compensation fixed sensor The ILT Series microcomputer chip and its sophisticated bi directional communi capabilities with the control panel achieves the of an Initiating Device ILT Series intelligent thermal detectors are compatible Cerberus Pyrotronics SensorLINK FPI 32 field The FPI 32 is a compact portable accessory which makes programming and detectors faster easier and more reliable than other The FPI 32 eliminates the need for cumbersome mechanical programming methods and reduces and service costs by electronically program addresses and functionally testing the ILT before the detector is installed ILT 1 thermal detector operates with either the IXL or the XL3 control panel ILT intelligent thermal detectors are UL listed ILT 1 is a plug in two wire thermal detector with either the IXL ICON MXL or XL3 control Each ILT 1 has microcomputer chip technology and stable solid state electronic circuitry ILT Series thermal detector consists of a rate temperature 135 rated sensor The consists of an aluminum tubular shell containing curved expansion struts under compression which are with a pair of normally open opposed contact The contact points are insulated from the shell The shell and struts have different coefficients of When subjected to a rapid heat rise the tubular expands and lengthens slightly At the same time the struts lengthen but at a slower rate than the shell NUMBER rapid lengthening of the shell allows the struts to come and close the contact points When the contact close an alarm is initiated subjected to a very slow heat rise the tubular shell the interior struts lengthen at approximately the same At the detector set temperature point of 135 the interior struts are fully extended and close the points which initiates an alarm The ILT 1 is shock corrosion resistant This detector responds only to so the ILT 1 is suitable for use in areas where prohibit the use of other types of detectors detector microcomputer chip has the capacity of in memory identification information as well as operating status information In addition the ILT Series detectors using their microcomputer chip can in either of two protocols One protocol type used when the ILT 1 Series detectors communicate with IXL ICON and MXL control panel and the other is used for XL3 communication the ILT 1 thermal detector is in alarm the LED blinks continues blinking until the system is reset at the panel Also any user defined system alarm and control by event functions are activated the detector goes into alarm FPI 32 Programmer Tester is used to program and the detector address The user selects the Program to enter the desired address The FPI 32 then automatically sets and verifies the as well as tests the detector The FPI 32 has batteries so a detector address can be by the user from the most convenient The user can also separately test the detector for When the user selects the Test Mode a series tests are automatically conducted and the user is whether the detector has passed or failed ILT 1 detector is compatible on the same MXL or XL3 circuit with other Cerberus Pyrotronics IL Series or Series addressable ionization or photoelectric X Series addressable thermal detectors MSI or Series addressable manual stations TRI or TRX addressable interfaces or CZM Series addressable zone modules The ILT 1 detector is on the same IXL ICON circuit with other IL detectors MSI Series manual stations and TRI interfaces ILT Series thermal detector is capable of operating Series remote alarm indicator or auxiliary relay or base The ILT 1 detectors use a surface mounting Model DB 3S which mounts on a 4 inch octagonal or single gang electrical box Relay base Model mounts to a 4 inch square deep electrical box base Model ADBI 60 also mounts to a 4 inch deep electrical box When a 4 inch square or 4 square deep box is used an optional finish ring for bases is available Model RA ADB DB 3S and the DB X3RS and ADBI 60 use screw terminals for all electrical connections and self contacts for reliability The bases also contain a for an optional concealed locking mechanism to unauthorized removal of the detector head Model DDataata XL3 INX input module contains four initiating circuits each circuit capable of supporting up to thirty ILT intelligent thermal detectors The MXL uses ALD circuits and the IXL and ICON loop circuits with each capable of supporting up to sixty ILT Series detectors SSppeecciifications detector or group of detectors require a two wire of minimum 18 AWG thermoplastic fixture wire in conduit or minimum 18 AWG limited energy cable without conduit if permitted by local codes Wiring should conform to local and Electrical Codes and to the control panel wiring T tapping is permitted only for Style 4 Class wiring and A and Arcrchhiitect addressable thermal detector shall incorporate a microprocessor based integrated circuit which provide communication with its compatible control All of the detector communication circuits shall be within the detector head No communication or address identification mechanisms shall be within the detector base The detector shall be Cerberus Pyrotronics ILT thermal detector which shall be with either a Cerberus Pyrotronics XL3 or MXL IXL ICON control panel The thermal detector shall of a rate compensation fixed temperature 135 sensor detector address shall be programmed with the use a portable programming accessory The programming shall be a Cerberus Pyrotronics FPI 32 The portable programmer shall be driven Once the desired address is entered the shall set and verify the address The accessory shall also be capable of testing detector functionality The detector address shall be by electronic means only No mechanical means such programming pins dipswitches or rotary dials shall be to set the detector address The detector shall capable of bi directional communication with the panel detectors shall be compatible on the same XL3 or initiating circuit with other Cerberus Pyrotronics ID 60 ILT Series or X Series addressable ionization or detectors X Series addressable thermal MSI or MSX Series addressable manual TRI or TRX Series addressable interfaces or CZM addressable conventional zone modules The Information Information Wt Thermal Detector Profile Mounting Base Mounting Base with Relay Series Audible Base Alarm Indicator for 4 Box Mounting Alarm Indicator for Box Mounting 3 Base Locking Kit Finish Ring for Bases shall be compatible on the same IXL ICON circuit with other Cerberus Pyrotronics ILT Series IL Series MSI manual stations or TRI Series detector shall be capable of operating one remote indicator or auxiliary relay or audible base The relay remote alarm indicator is normally activated by the detector however the XL3 or MXL system shall capable of being programmed to operate the relay or alarm indicator independently of the associated All detectors and or relay
