ENGINEER AND ARCHITECT SPECIFICATIONS Series Remote Annunciators LED 1 and LED 2 8 Separate Points or Zones for Annunci either Trouble or Alarm Conditions Contemporary LED Annunciator Surface or Semi flush Installation Operates on the IXL Network Communi Line Field Programmable Listed ULC Listed FM CSFM and NYMEA Approved Pyrotronics Remote LED Annunciator units are to be used with the IXL Control Panel It is an annunciator containing sixteen LED for the of trouble and alarm status or initiating devices Series Remote Annunciators can be located in the lobby or in a protected area In its quiescent of operation all LED are off In the event of an a red LED will light to indicate which device or zone in alarm To report troubles i e removal of a detector the corresponding yellow LED will light indicating devices have been programmed as a single zone only one LED will light regardless of the number of in that zone indicating the trouble condition The Annunciator may be tested by using the Lamp feature of the Control Panel perform the important service of pinpointing location of the alarm device or the zone from which an originates and Architect Specifications LED annunciators will have LED for Alarm and per point There will be eight points per annuncia and it shall be connected to the IXL Network Communi Line This annunciator shall be addressable and not require DIP switches or jumper settings for its The remote LED annunciator shall be Pyrotronics model LED 1 LED 2 actuation of a zone the corresponding red LED will Each additional actuated zone will light its corre LED The Remote Annunciator can be tested the Lamp Test feature of the Control Panel to indicate functioning of the LEDs LED annunciators are field programmable Field for the LED Series Remote Annunciator must performed when a new unit is installed Annunciators programmed by placing the Control Panel in the mode and the next available address will be to the annunciator when it has the programming applied to it Series Remote Annunciators must be installed in accessible locations The unit s can be semi flush mounted using a single gang electrical box Multiple NUMBER Information No No e s c r i p t i o n E D 1 Annunciator Unit White E D 2 Annunciator Unit Black Cabinet Max 12 or LED 2s Annunciators may be mounted side by side by modular electrical boxes Add two additional gangs each additional Remote Annunciator i e use a three box for two annunciators Remote Annunciators can connected to the Network Communication Line by the screw terminals provided on the module and Environmental Power Current VDC Alarm LEDs only All LEDs lit Temperature 0 to 49 Humidity Cabinet for Units 12 max 245 8 x 141 2 x 5 5 8 Single Units Single gang electrical box non condensing H x 35 8 W x 11 16 D oz Diagram The use of other than Cerberus Pyrotronics detectors and bases with Cerberus control equipment will be considered a misapplication of Cerberus Pyrotronics and as such void all warranties either expressed or implied with regards to loss liabilities and or service problems Pyrotronics Ridgedale Ave Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1994 sheet dated 8 93
