MC 3 Tone Signaling Devices Horn and Horn Strobes AND ARCHITECT SPECIFICATIONS Three Unique Sounds Low Operating Current High dB Output ADA UL 1971 Horn Strobe Versions Available in Flush Surface or Mount Standard 4 inch Square Mounting Listed ULC FM CSFM NYMEA Pending Cerberus Pyrotronics F Series of horns and horn combines high quality electronics with the rugged of a metal housing providing the penetrating power of an electromechanical horn while eliminat the inrush and RFI noise problems associated with signals These units are designed for ADA and meet the latest requirements of NFPA 72 National Fire Alarm Code and UL 1971 standards for devices for the hearing impaired three distinct sounds HORN SIREN WARBLE are selectable The energy efficient horn design draws 20 mA while supplying 100 dB at 10 feet Screw are provided for both the horn and strobe and be configured to operate together or independently are available for flush surface or ceiling installation strobe versions utilize a Xenon flashtube with solid state for maximum reliability and efficiency Strobes are in 15 15 75 75 and 110 Candela ratings with mounting configurations The strobe lens has a material made of white Lexan with 5 8 red The top of the strobe has a rounded dome shape of clear Lexan The overall lend height is 2.5 with a of 1.25 S15 model provides 15 cd and are used in non sleeping where lower candela is required per UL 1971 S17 model is for non sleeping installations requiring 15 output while also providing an ADA compliant 75 cd output for public areas S75 version offers a 75 cd polar output that meets ADA for regular lighted public areas while also UL 1971 in substitution of multiple 15 cd units S110 version intensifies a non sleeping ADA area with cd and can be used in sleeping areas to help wake the impaired person per UL 1971 NUMBER No No VDC VDC VDC VDC Ratings VDC Ratings dB 10 dB 10 mA mA mA Horn Ratings Horn Ratings Strobe Current Ratings mA Strobe Current Ratings mA No No dB 10 dB 10 F S C VDC VDC VDC mA mA mA Only 15 17 units available in ceiling mount Minimum UL measurements are 75 dB 12 VDC 85 dB 24 VDC taken in a reverberant room represents strobe model e g 15 17 75 or 110 Diagram No Surface Box Red Surface Box for Flush Horn Strobe Red Wall Ceiling Housing for Bi Directional Flush Horn Strobe Plate Red Conduit Plate Red The use of other than Cerberus Pyrotronics detectors bases with Cerberus Pyrotronics control equipment will be a misapplication of Cerberus Pyrotronics equipment as such void all warranties either expressed or implied with to loss damage liabilities and or service problems Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1996 sheet dated 2 96
