Cerberus Pyrotronics MMM-1 Microphone Master Module 5025

MMM 1 Microphone Master Module AND ARCHITECT SPECIFICATIONS Dynamic Microphone with Button Retractable Coil Cord Fully Supervised Adjustable Pre announce Tone Ready To Page LED Local Speaker with Volume Recording Output on TBM 2 ULC Listed FM CSFM City of Approved MMM 1 is an MXLV module which provides a super high quality dynamic microphone for the purpose of live voice announcements The MMM 1 mounts to the MKB 2 display keyboard in the front of the command console It includes a microphone with button and retractable coil cord The micro push to talk button and coil cord are fully super MMM 1 also supplies a ready to page LED which that all selected zones are ready to be paged that the optional pre announce tone has expired The tone is a 900Hz signal which is adjustable 0 to 10 seconds duration in 1 second increments A speaker with volume control allows the monitoring of audio channels and Architect Spec and Architect Speciiffications emergency voice alarm system shall include a micro for the purpose of making live voice announce The microphone master module shall mount in the of the command console and provide a high quality microphone with push to talk button and retract coil cord The microphone push to talk button and cord shall all be electrically supervised module shall also include a ready to page LED which indicate that all selected zones are ready to be paged the optional pre announce tone has expired The pre tone shall be a 900Hz tone adjustable from 0 to seconds duration in 1 second increments A local with volume control shall allow the monitoring of audio channels NUMBER Information Information Number Master Instructions Diagram Diagram the Cable to the ACM 1 the Cable to the ACM 1 2 the MMM 1 on the MKB 2 Panel 1 The use of other than Cerberus Pyrotronics detectors and bases with Cerberus Pyrotronics equipment will be considered a misapplication of Cerberus equipment and as such void all warranties either expressed or implied with regards to loss damage liabilities and or service problems Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 www cerbpyro com in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1997 sheet dated 8 94
