MOM 4 Option Module Card Cage Four Half Width or Two Full Width AND ARCHITECT SPECIFICATIONS Provides Input Terminals for Module Slots Clamp Type Screw Terminals Field Wiring Connections Mounts in MXL Main Cabinet MXLR Remote Units Gold Plated Connectors DC Power Accepts CRM 4 CZM 4 ALD 2I NET 7 CMI 300 REP 1 NIM 1R and ULC Listed CSFM NYMEA and City of Chicago Approved MOM 4 card cage provides the MXL main unit or units with card slots for option modules Each supplies connection space for either two full width modules ALD 2I CZM 4 NIM 1R XLD 1 or four option modules CSM 4 CRM 4 CMI 300 NET 7 or a combination of one full and two half modules Note only one CMI 300 may be used per system Modules are supplied with card guides MOM 4 also provides a means of connecting the modules to the MXL network It supplies 24V DC and 5VDC to power the option The DC is routed to the MOM 4 from the MMB 1 board or the PSR 1 power supply terminals are mounted on the MOM 4 to provide access for field wiring connections Screw terminals also provided for connection to an auxiliary power for use with CSM 4 indicating circuits when audible visual power is required MOM 4 mounts in one of the MXL system back boxes at the main MXL or MXLR remote units Up to two may be installed in the MBR 1 backbox only one TSP 40 printer is used Up to three MOM 4s may be in the MBR 2 backbox only two when TSP 40 is used and Architect Specifications between optional circuit cards and the MXL network shall be provided by a MOM 4 expansion cage The MOM 4 shall provide two full width edge plug in slots for the addition of the follow system option card modules CZM 4 conventional module NIM 1R LifeLINK Network Interface Module Series Device Module REP 1 Network Re NET 7 Style 7 Network Module CRM 4 controllable module CSM 4 controllable signal module ALD 2I loop driver module CMI 300 CXL modem The CZM 4 NIM 1R and XLD 1 shall occupy one full in MOM 4 and CRM 4 REP 1 NET 7 CSM 4 and CMI shall each occupy one half slot in the MOM 4 MOM 4 shall also provide a distribution point for module power The MOM 4 shall supply necessary terminal connections for any option module field This shall allow the replacement of modules without removal of field wiring MOM 4 shall be mounted in one of the MXL system located at the main MXL unit or MXLR remote NUMBER Data Circuit Board Layout MXL Modules Number Interface Module Crt Module Module Zone Module Repeater Module Interface Module Series Device Interface Loop Driver Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1996 sheet dated 9 95
