Cerberus Pyrotronics PIM-2 Printer Interface Module 5044

ENGINEER AND ARCHITECT SPECIFICATIONS Interface Module MXL Supervised Parallel Printer Interface CXL Supervised Printer Interface Supervises Any UL EDP Listed Parallel Printer Supervises the PAL 1 UL 864 Listed Printer Interfaces to PIM 1 on MXL and CXC 2 CXL Configuration Dipswitches Plug in AC Power Transformer Supervises Printer for On Off Line On Paper Out Paper Jam Wiring Faults Serial to Parallel Data Conversion ULC Listed CSFM and Approved PIM 2 module is an interface that allows the con of UL listed EDP Centronics parallel printers to MXL and CXL systems It converts the RS 232 printer outputs of the MXL and CXL to a parallel interface PIM 2 includes a plug in AC power transformer supplies power to the unit NFPA 72 proprietary require that the PIM 2 transformer be con to a UL listed UPS The unit also provides a set dip switches for configuration It supervises either a Centronics type parallel printer or a PAL 1 UL parallel printer is used in conjunction with the PIM 1 when connected an MXL system It allows the MXL and CXL to fully the attached printer for Power On On Off Paper Out Paper Jam It also supervises the wiring the MXL or CXL and the printer and Architect Specifications system shall be provided with a fully supervised UL parallel printer Conversion from RS232 serial data parallel format shall be accomplished using the PIM This unit shall include configuration dipswitches and allow either the Cerberus Pyrotronics MXL or CXL to fully supervise the printer for all possible conditions including Paper Out Paper Jam On Off Power On and any wiring faults between the and the printer PIM 2 shall include a plug in AC power transformer used in an NFPA 72 proprietary type system a UL UPS shall provide power to both the PIM 2 and printer used with an MXL system the PIM 2 shall be to the PIM 1 serial module When used with a system the PIM 2 shall be connected directly to printer port on the CXL s CXC 2 module which do not supervise the printer for wiring will not be considered equal NUMBER Wiring Diagram Maximum cable distance from PIM 1 to PIM 2 cable is 25 The two modules must be in the same room maximum distance from the PIM 2 to the parallel is 6 feet The two modules must be in the same power PWR is connected to the 5 VDC 600mA supplied with PIM 2 The transformer requires VAC 60 Hz 0.5A max NFPA 72 local Auxiliary and Remote Station configura connect the output of the PIM 2 to any UL listed EDP parallel printer parallel printer must support the EPSON FX com set input and output connectors are DB 25 female RESET on the PIM 2 causes the unit to read the settings The status LED is lit when the unit is Do not use the COPY button NFPA 72 Proprietary and UL 1076 configurations use printer Model PAL 1 a UL listed for fire Centronics parallel printer parallel printer is supervised for AC on off line paper paper jam and connection to the PIM 2 The PIM 2 is supervised for power connection to the and connection to the PIM 1 1 Serial Interface Communication Parameters Wiring Diagram Maximum distance from PIM 2 to parallel printer is 6 feet modules must be in the same room PIM 2 power PWR to the 5 VDC 600mA supplied with PIM 2 The transformer 120 VAC 60 Hz 0.5A max input and output connectors are DB 25 female RESET on the PIM 2 causes the unit to read the settings The status LED is lit when the unit is Do not use the COPY button revision 8.0 or higher of CXL firmware to support this is supervised for AC on off line paper out paper and connection to PIM 2 is supervised for power connection to printer and TO NOTES 6 AND 7 IT IS NOT SUPERVISED DATA INTEGRITY BETWEEN AND THE PRINTER IN UL LISTED ELECTRICAL BOX Information Number Printer Interface Instructions Pyrotronics Ridgedale Ave Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1996 sheet dated 7 95
