Cerberus Pyrotronics ZB-35 Linear Beam Smoke Detector Zone Module 3110

System 3 Input Module Module AND ARCHITECT SPECIFICATIONS ZB 35 Linear Beam ZB 35 Linear Beam Detector Zone Module Detector Zone Module Two Wire Circuit eliminates need separate power wiring to the detector Low Cost Installation Style B Class B Two Zones Placement Supervised Power Limited Listed ULC Listed CSFM NYMEA Approved Cerberus Pyrotronics Linear Beam Smoke Detector Zone Model ZB 35 is designed to accommodate the Pyrotronics Linear Beam Smoke Detector Model on only a two wire initiating circuit Class B Style B additional power or other interface wiring is required The module is connected to the System 3 via the 10 pin structure ZB 35 is a System 3 module that occupies 2 module This module contains two separate zones Each supports either one set of PB 1191 Beam Smoke or up to thirty compatible smoke detectors A does not support a mix of a beam detector and smoke regulated zone output circuit may be connected in a B Class B installation Refer to Figures 1 and 2 Use 2K ohm 1 2W 1 resistor for supervision A shorted line is current limited to 120mA maximum circuits are power limited per NFPA 70 National Code ZB 35 contains separate output terminals for use with and trouble conditions An alarm is locked in until the is reset An alarm always overrides any trouble A zone trouble does not lock in Specifications model ZB 35 System 3 Module shall be used to accommo a Cerberus Pyrotronics Linear Beam Smoke Detector PB 1191 The ZB 35 Module shall use a two wire circuit Style B Class B additional power or other interface wiring shall be re The ZB 35 Module shall be connected to the System via the 10 pin bus structure ZB 35 module shall contain two separate zones to the PB 1191 Beam Detector The ZB 35 may be used with compatible smoke detectors and manual Each zone shall support either one set of PB 1191 Beam Smoke Detectors or up to thirty compatible detectors A zone shall not support a mix of beam and smoke detectors ZB 35 will contain separate output terminals for use with and trouble conditions An alarm shall be locked in until system is reset An alarm shall always override any indication A zone trouble shall not lock in NUMBER Information Requirements Standby 15 mA per Zone 120 mA per Zone Information Description Dual Zone Linear Beam Module 9kb to Installation Instruction P N 315 090067 Diagram with PBA 1191 Beam Detector Connections with Smoke Detector Connections 1 2 The ZB 35 zone may be connected as either Class A or Class B to Figures 1 and 2 Do not connect more than one PB 2400 Bean Detector in each zone The maximum total detector line resistance is 40 ohms Do not mix smoke detectors and beam detectors on the same zone Place an EOL resistor across any terminals where a zone is not used All wiring should meet local requirements Connect terminals 1 6 7 and or 12 to annunciator or Relay Module or equivalent use up to 30 smoke detectors from any of the compat detectors listed at the right or use shorting devices detector or remote lamps Refer to related detector instruction For see Notes 2 and 4 DETECTORS is the compatibility identifier The use of other than Cerberus Pyrotonics detectors and bases Cerberus Pyrotronics control equipment will be considered a of Cerberus Pyrotronics equipment and as such void all either expressed or implied with regards to loss damage and or service problems Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1996 sheet dated 1 95
