Cerberus Pyrotronics ZU-35 DS Input Module 3107

System 3 Input Modules ZU 35 ZU 35DS ZU 35TS Dual Zone AND ARCHITECT SPECIFICATIONS Complete Supervision Of Detection Class A Style D and Class B Style B Accommodates Ionization Photoelectric Flame Detectors Manual and Other Contact Devices Alarm And Trouble LEDs Per Zone Listed ULC Listed FM CSFM NYMEA Approved ZU 35TS Coast Guard Approved Cerberus Pyrotronics Dual Zone Module Model ZU is designed to provide two independent initiating Up to thirty standard Cerberus Pyrotronics and photoelectric detectors or flame detectors model DF 3 DF 3A and DF 30 are supported by modules Additionally any quantity of shorting type devices such as manual stations and thermal also can be accommodated and intermixed on initiating circuit Terminals are provided for each power limited in either NFPA Class A Style D or Class B Style addition to all the same features of the ZU 35 each is provided with a disconnect switch which will the zone This action will cause a zone trouble a system trouble signal until the switch is returned to ZU 35TS is furnished with a 3 position momentary test switch for each zone The normal switch is in the center one side position will test the trouble signal and the other will test a zone alarm This is a requirement for US Coast Guard ap for use on marine systems and the module is Guard approved operation of a detector or shorting type device on the initiating circuit the module will lock into alarm condition initiating the start of the sequential designed into the system These functions may sounding audible devices operating alarm closing doors shutting down fans and recalling elevators and other similar func required for life and property safety addition to the system alarm a red Alarm LED on the of the dual zone module will be illuminated for that detection circuit A trouble on either detection will be similarly annunciated with a yellow LED for each circuit NUMBER module supplies a current limited output signal for circuit in alarm providing for activation of supplemen modules or annunciators dual zone module occupies one module space in the 3 rail structure and is interconnected via a ten plug and harness assembly Dual Zone Module Model ZU 35 DS TS is Underwrit Laboratories Inc listed and FM approved equipment is approved for operation over the range of 0 to 49 Archiitect S Sppececiifficicaations aand Arch initiating circuit line monitoring shall be provided a Cerberus Pyrotronics Dual Zone Module Model ZU ZU 35DS or ZU 35TS This module shall be system by a ten pin plug and harness and shall operable with the main control panel zone circuit shall accommodate up to thirty current Cerberus Pyrotronics detectors except for model which is limited to 5 devices Any quantity of type contact devices such as thermals and stations can also be intermixed on a zone circuit detection circuit shall consist of either NFPA Class Style D or Class B Style B operation of any initiating device installed in the the module shall lock into alarm and the red LED indicating lamp one for each circuit mounted on face of the module shall illuminate A yellow LED indicator one for each circuit also on the face of module shall illuminate should a break occur in the circuit wiring or a detector be removed from the of alarm conditions shall have priority over and shall be annunciated over any trouble LED indicators shall be lamp tested from the system panel Model ZU 35 ZU 35DS or ZU 35TS shall be place supervised and shall be Underwriters Laboratories listed and FM approved Rl Raattiingsngs Requirement 23.5 VDC mA mA Information Information No Wt Zone Module lb 45 kg 500 887255 lb 45 kg Zone Module with Zone Disconnect except w trouble test switches S C G approved 500 885420 lb 45 kg Wiring for Wiring for ZU 35DS ZU35TS ZU 35DS ZU35TS 760 760 A Style D Initiating Circuits 18 1 23.5 VDC 9mA 275mA Total zone initiating circuit resistance 36 ohms 9 ohms per line Unused spare zones must have EOL device See individual detector for actual terminal numbers Maximum of 30 detectors combination of those listed on the table at right are allowed per circuit Also may use detector remote lamp or detector relay indicated on the applicable detector Detectors 315 081943 315 085257 315 085257 315 081943 315 086590 315 094963 315 086593 315 094198 315 090875 315 086441 315 086545 is the compatibility identifier B Style B Initiating Circuits 18 3 23.5 VDC 9mA 275mA Total zone initiating circuit resistance 36 ohms Unused spare zones must have EOL device See individual detector for actual terminal numbers Maximum of 30 detectors combination of those listed on the table at right are allowed per circuit Also may use detector remote lamp or detector relay indicated on the applicable detector Detectors 315 081943 315 085257 315 085257 315 081943 315 086590 315 094963 315 086593 315 094198 315 090875 315 086441 315 086545 is the compatibility identifier Pyrotronics Ridgedale Avenue Knolls NJ 07927 201 267 1300 201 397 7008 www cerbpyro com in U S A Pyrotronics East Pearce Street Hill Ontario 1B7 CN 905 764 8384 905 731 9182 1997 sheet dated 10 95
