s Sheet Safety Products Bases Audible Sounder Base designed for sleeping areas ABHW 4S AND ENGINEER SPECIFICATIONS Meets NFPA 72 code requirements for Hz square wave tones in sleeping areas Meets NFPA 720 carbon monoxide CO requirement for 4 tone with 520 Hz in sleeping areas Minimizes footprint on the wall or ceiling One 1 box solution Offers highly flexible programming and configuration with independently controlled outputs by device Provides six 6 field configurable audible tone patterns Steady American National Standards Institute ANSI Temporal 3 ANSI Temporal 4 Carbon Monoxide CO March time 120 and Canadian March time 30 can also follow the Siemens fire alarm control panel FACP appliance circuit NAC output Compatible with Desigo Fire Safety intelligent devices Siemens and detectors Overview Model ABHW 4S Audible Sounder Base from Fire Safety is an intelligent supervised base designed for use in sleeping areas of a Each Model ABHW 4S base generates a 520 Hz audio signal complying with NFPA 72 as well as with UL ULC Listed applications ABHW 4S provides six 6 field configurable tone two 2 volume levels are used with compatible detectors and FACPs Steady Temporal 3 and Canadian March Time 30 are supported by intelligent audible base for sleeping areas ABHW 4S is fully compatible with all Siemens detectors listed in the detector tables in this document to the Details for Ordering section on Page 2 used in conjunction with other listed compatible fire safety components Model ABHW 4S may be in lieu of single multiple station smoke alarms to enhanced system level functionality ABHW 4S meets the requirements specified in ULC S525 ULC S529 as well as UL464 which includes 520 Hz low frequency for Area View View Bases for sleeping areas compatible with Desigo Fire Safety fire alarm control panels FACPs FireFinder XLS FACPs Siemens PAD series NAC Extenders UL268 UL464 UL2075 Listed ULC S525 S529 FM 3150 3230 3010 and CSFM Approved ABHW 4S is made up from a standard Siemens Series detector base layout and has supportive circuitry for FACPs and Model detectors each Model ABHW 4S base houses a pre audible sounder device capable of generating a Hz square wave tone that produces a signal up to at 10 ft 3.1m for localized annunciation power options are available for the Model ABHW audible base and can therefore be powered in a usual configuration via use of any one 1 of the a notification appliance circuit NAC a PAD series NAC extender Model ZIC 4A or any Listed 24VDC regulated power supply See the Model ABHW 4S Installation and Operation IOM A6V10405588 for further details ABHW 4S bases are capable of sounding individually or in any combination it is upon the detector type and when it used and with a compatible Siemens FACP When Model ABHW 4S bases are used with Model detectors functionality is limited and is similar to Model ADBH 11 audible base ABHW 4S Audible Base for Sleeping Areas 6160 Industry Inc Technologies Division ABHW 4S is a UL ULC Listed supplementary device that meets or exceeds the 85dB 10 ft 3.1m audibility requirement specified in ULC S525 ULC S529 as well as UL464 including the low frequency requirement of Hz for Areas Data smoke detectors used with Model ABHW 4S are to the maximum 30 ft center spacing sq ft as referred to in the National Fire Association Standard 72 This spacing is based on ideal conditions namely ceiling no air movement and no physical between the fire source and the detector aforementioned center spacing format should be to as a guide for detector installation layout not mount detectors in areas close to ventilating or outlets Exposed joists or beamed may also effect safe spacing limitations for is mandatory for NFPA 72 guidelines and good judgment be applied to detector and spacing with s FACPs ABHW 4S works with the following panels XLS FC2005 FC2025 FC2050 Data Humidity Output Type Machine Interface PMI or later Custom Configuration Software or later Loop Card Model DLC or later 50 point addressable FACP 24 v01.02.16 53 v6.0.0R1 or later 120 49 95 85 dB 75 dB Temporal 3 Box 4 Temporal 4 low power Time 120 March Time 30 cm 4 inch square gang box A 4 10.2 cm octagon box is not compatible with Model ABHW 4S Data Cross Cable 18 AWG Wire Gauge 2 back end blocks of up to four screw terminals on each side Voltage Current Power 16 33 VDC Power 16 33 VDC SLC Loop 250 External Source 1.0 mA Current max dBA 65 mA 33VDC dBA 90 mA 24VDC dBA 165 mA 16VDC dBA 0.85 mA from loop dBA 28 mA 33VDC dBA 33 mA 24VDC dBA 45 mA 16VDC dBA 1.6 mA from loop for Ordering S54320 F14 A1 for sleeping areas S54320 F14 A2 Sleeping Room Version 520 Hz Audible Sounder Base Base COO USA Intelligent Detectors Detector Detector Heat Detector Heat Detector Optical Heat w CO Detector Remote Lamps Series Detectors Remote Alarm Lamp Wall Remote Alarm Lamp Ceiling Optical Heat Detector Heat Detector Optical Detector Optical Heat Detector Heat Detector Optical Detector Models SFP 11 SFPO 11 and SFPT 11 detectors are approved in Canadian installations Model bases limited in audible base functionality Technical Support at 1 800 248 7976 for more details This marketing data sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www usa Siemens com Fire in U S A Safety North Service Road Oakville Ontario 0H6 Canada 905 465 8000 www Siemens CA 2016 sheet dated 3 2015 4
