Installation Instructions ADB 11 Base ADB 11 Model ADB 11Audible Base consists of a standard Series 11 base with an audible device The ADB 11 is an audible base used only with 11 conventional detectors DT 11 PE 11 11T and is powered directly the zone circuit Refer to Table 1 for compatible detector model numbers the related Installation Instructions All field wiring terminates at a four terminal block located on the back of the unit The audible device when the detector alarms and stops sounding when the system is Refer to Figure 1 the ADB 11 Audible Base Terminal Blocks and 2 the ADB 11 Wiring Diagram Only one device is guaranteed to per zone ADB 11 can generate either steady or temporal tone with the insertion of a at the terminal block NEXT DB 11 OR ADB 11 USED FOR SELECTION INITIATING CIRCUIT OF CONTROL PANEL Audible Base Terminal Blocks 1 Industry Inc Technologies Division Park NJ 315 096162 8 Building Technologies Ltd Safety Security Products Kenview Boulevard Ontario L6T 5E4 Canada of not use looped wire under Terminal 5 of DB 11 base Use a break in the wire at the to provide supervision of connection tone select and select are unconnected without a jumper select and select are shorted insert a jumper Panels CP 2ER CP 2HR System 3 MXL MXL IQ CZM 4 only and PXL PE 11T and DT 11 2 Installation Wiring Diagram NOTE ADB 11 is a UL268 listed smoke detector supplementary device which detector base and audible device functions It meets or exceeds the dB at 10 foot audibility requirement for smoke alarms as specified in Single and Multiple Station Smoke Alarms and NFPA 72 for sleeping When used in conjunction with listed compatible Siemens equipment ADB 11 may be used in lieu of single multiple station smoke alarms to enhanced system level functionality Typical applications are sleeping in hotels guest suites dormitories day care and residential board and facilities as designated in NFPA 72 RATINGS AND CONSTRAINTS ADB 11 Rating 17 31 VDC Supervisory 0A 24mA at 25 VDC Only one device is guaranteed to activate per zone PLACEMENT table below lists the detectors that can be used with the ADB 11 Detector along with the appropriate Installation Instructions though no specific spacings are allocated to the detectors used with bases use 30 foot center spacing 900 sq ft as referred to in NFPA 72 National Fire Alarm Code Chapter 5 and CAN ULC S254 as a or starting point if practical in a detector installation layout This spacing based on ideal conditions ceiling no air movement and no physi obstructions all installations except in special circumstances like computer room locate the detector on the ceiling a minimum of 6 inches from a wall or on a wall between 4 and 6 inches from the ceiling questions arise regarding detector placement it is extremely important that drawings provided or approved by Siemens Industry Inc or by its autho distributors be followed The detector placements shown on these draw were chosen after a careful evaluation of all facets of protecting the area factors such as air current temperature humidity air pressure the nature of the fire load are carefully considered Special consideration is to room or area configuration and the type of ceiling sloped or flat or beamed Siemens Industry Inc s extensive experience in the of fire detection systems assures optimum detector placement and is in these drawings Follow sound engineering judgment made by personnel WIRING THE ADB 11 BASE base model ADB 11 should be interconnected as shown in the Diagrams above and wired to the specific system modules control panels following the appropriate instructions MOUNTING THE ADB 11 BASE detector base comes from the factory prewired All signaling and initiating are connected directly to the back of the ADB 11 audible base using the terminal blocks The Audible Base Model ADB 11 attaches only to a 4 inch square box with extension the Detector Base Route all wires out from the outlet box When the alarm LED viewing is critical position the LED mark on the base in intended direction Refer to Figure 3 Make connections directly to the audible base terminals located on the back the base Refer to the related lnstallation Wiring Diagram above After all bases are installed check loop continuity Refer to System manual the loop continuity checkout procedure For ADB 11 loop continuity use the jumper furnished in every base between terminals 1a and to complete the loop Refer to Figure 3 An open circuit condition exists the jumper or detector is installed in the base If loop continuity is acceptable remove the jumper at each base and with detector head installation I N LED WITH BASE 3 the Alarm LED CONTROL EQUIPMENT FOR ADB 11 Identifier System 3 MXL MXL IQ SXL EX SXL EX System 3 575 293737 7 575 287232 9 315 084902 22 315 090726 9 315 094131 5 315 095997 6 315 096018 5 315 096022 5 315 083222 15 detector model number is the compatibility identifier Industry Inc Technologies Division Park NJ 315 096162 8 Building Technologies Ltd Safety Security Products Kenview Boulevard Ontario L6T 5E4 Canada
