Siemens AH Horn Series and AS Horn Strobe Series Appliances, Data Sheet

s Sheet Safety Products Appliances AH Audible Horn Strobe Audible Horn Appliances Application Indoor Outdoor Overview Fast installation with In Out screw terminals using 12 to 18 AWG wires Synchronization can be done via the Siemens 50 point 252 point and 504 point alarm control panels FACPs as well as with FireFinder XLS and MXL FACPs PAD 3 or PAD 4 NAC Extenders with built in sync protocol Siemens Dual Sync DSC modules Selectable Continuous Horn or Temporal Code 3 Wall mounts are available with field selectable Candela settings 15 30 75 110cd or 135 185cd Ceiling mount models are available with field selectable Candela settings or 115 177cd multi Candela ceiling models Three 3 field selectable dBA settings of 90 95 99 dBA Anechoic in both tones Weatherproof wall mount models are available with field selectable Candela settings 135 185cd Weatherproof ceiling mount models are available with field selectable Candela settings 115 177cd Listed ULC Listed 3150 and CSFM Approved 7125 0067 0247 Fire Alarm Devices For The Hearing Impaired ADA NFPA UFC ANSI compliant Notification appliances are Siemens Series Audible Horn Strobe appliances and Audible Horn appliances or approved equals Series Audible Horn Strobes are listed for UL Standard 1971 Devices for the Hearing Impaired for Indoor Fire Protection Service Series Audible Horns are UL Listed under Standard 464 Fire Protective Signaling All inputs are compatible with standard reverse polarity supervision of circuit wiring by Siemens Fire Alarm Control Panel FACP The audible portion of each appliance has a minimum of three 3 field selectable settings for dBA levels as well as a choice of continuous or temporal Code 3 audible outputs The strobe portion of each appliance produces a flash rate of one 1 flash per second over the Input Voltage Range and incorporate a Xenon flashtube enclosed in a rugged Lexan lens AH Series Notification Appliances 2578 Industry Inc Technologies Division continued Series Horn Strobe appliances are of low current design Strobe intensity where Multi Candela appliances are specified is easily by field selectable settings and is rated per UL Standard 1971 for 15 30 75 110cd 135 185cd When synchronization is required Series horn strobe appliances are compatible with the 50 point 252 point and 504 point fire alarm control panels FACPs as well as with Siemens DSC modules XLS and MXL FACPs or PAD 4 NAC Extenders with built in sync protocol The strobes will not drift out of synchronization at any time during operation The strobes will revert to a non synchronized flash rate if the sync module or Power Supply fail to operate i e contacts remain closed The appliance is also designed so that the audible signal may be silenced while maintaining strobe when used with Siemens synchronization The Series Horn Strobe and Series Horn appliances incorporate a Patented Universal Plate that allow mounting to a single gang double gang 4 inch 10.2 cm square SHBBS Series surface backbox All notification appliances are listed for Special Applications are designed to flash at 1 flash per second minimum over their Input Voltage Range Note NFPA 72 specifies a flash rate of 1 to 2 flashes per second and ADA Guidelines specify a flash rate 1 to 3 flashes per second All Candela ratings represent minimum effective Strobe intensity based on UL Standard 1971 Diagram Shown In Inches Options Shown In Inches Industry Inc Technologies Division Data Series Wall Mount Ratings AMPs Series Ceiling Mount Ratings AMPs RMS Current with Hi dBA Setting RMS Current with Hi dBA Setting Voltage 16.0 33.0VDC 16.0 33.0VRMS 0.134 Voltage 16.0 33.0VDC 16.0 33.0VRMS 0.144 Ratings AMPs Ratings AMPs RMS Current with Med dBA Setting RMS Current with Med dBA Setting Voltage 16.0 33.0VDC 16.0 33.0VRMS 0.119 Voltage 16.0 33.0VDC 16.0 33.0VRMS 0.132 Ratings AMPs Ratings AMPs RMS Current with Low dBA Setting RMS Current with Low dBA Setting Voltage 16.0 33.0VDC 16.0 33.0VRMS 0.112 Voltage 16.0 33.0VDC 16.0 33.0VRMS 0.122 Series Wall and Ceiling Mount Ratings AMPs Voltage RMS Current with Hi dBA Setting 16.0 33.0VDC 16.0 33.0VRMS 0.499 Series Weatherproof Ceiling Mount Ratings AMPs RMS Current with Hi dBA Setting Voltage 16.0 33.0VDC 16.0 33.0VRMS Ratings AMPs Ratings AMPs RMS Current with Med dBA Setting RMS Current with Med dBA Setting Voltage 16.0 33.0VDC 16.0 33.0VRMS 0.509 Voltage 16.0 33.0VDC 16.0 33.0VRMS Ratings AMPs Ratings AMPs RMS Current with Low dBA Setting RMS Current with Low dBA Setting Voltage 16.0 33.0VDC 16.0 33.0VRMS 0.488 Voltage 16.0 33.0VDC 16.0 33.0VRMS Series Weatherproof Wall Mount Ratings AMPs RMS Current with Hi dBA Setting Voltage 16.0 33.0VDC 16.0 33.0VRMS Ratings AMPs RMS Current with Med dBA Setting Voltage 16.0 33.0VDC 16.0 33.0VRMS Ratings AMPs RMS Current with Low dBA Setting Voltage 16.0 33.0VDC 16.0 33.0VRMS Industry Inc Technologies Division Series Weatherproof Wall Ceiling Mount Ratings AMPs Voltage RMS Current with Hi dBA Setting 180cd UL1971 UL1638 16.0 33.0VDC 16.0 33.0VRMS Ratings AMPs Voltage RMS Current with Med dBA Setting 180cd UL1971 UL1638 16.0 33.0VDC 16.0 33.0VRMS Ratings AMPs Voltage RMS Current with Low dBA Setting 180cd UL1971 UL1638 16.0 33.0VDC 16.0 33.0VRMS
