Siemens CDC-4 Desigo Modular Conventional Detector Card, Data Sheet

Fire Safety system Detector Card CDC 4 Architect Engineer Specifications Supports up to 30 Siemens smoke detectors per zone Four 4 Class A Class B zones Also supports various detectors by other manufacturers Product Overview Conventional Detector Card Model CDC 4 is used to monitor Siemens conventional detectors on the Desigo Fire Safety Modular Desigo Modular control panel FACP Model CDC 4 can be used in applications where detectors are more suited than addressable detectors such as or large meeting rooms Supports unlimited devices per zone Custom message zone available Mounts into a single slot of a 2 slot Model CC 2 or Model CC 5 card cage Ground fault detection Plain decimal address setting Optional alarm by circuit Built in status and light emitting LEDs UL864 CAN ULC S576 Listed CSFM NYC Fire Approved CDC 4 can also be used to upgrade Siemens conventional panels to the Desigo Modular system without detector replacement Specifications of the four 4 conventional zones can be wired Class A D or Class B Style B Up to 30 conventional photo photo thermal detectors can be wired to a single A single zone can optionally support a single beam Additionally each zone can have an unlimited number normally open N O contact devices such as manual pull and thermal detectors detectors can use any variation of an audible base a relay a remote LED The appliance will activate when that detector into Alarm mode Each zone can operate the appliances with the first smoke detector in Alarm mode each zone can also be configured to operate with the Verification feature This feature helps reduce nuisance by automatically verifying an Alarm event received on the caused by smoke detectors The zones can also each be for degrade operation allowing partial system functions the system loses contact with the main system control unit Model CDC 4 Card operational characteristics and the custom message for each zone are programmed the ZEUS D programming tool and is stored within the system Addressing Model is performed using the integral 3 three position decimal address switches on the front of the card LEDs on Model CDC 4 give indication of power communication ground alarm by circuit and trouble by circuit These LEDs aid in troubleshooting found on a system A local reset switch for Model CDC 4 card is also provided CDC mounts in a single slot of a Model CC 5 or Model CC 2 card cage wiring for Model CDC 4 is connected to the upper terminals on the card while 24VDC is wired to the lower terminals for powering the zones Technologies Division usa siemens com desigo fire safety Data Sheet 7328 Compatibility Tables SIEMENS FIRE SAFETY DETECTORS Maximum 30 per zone unless indicated Four 4 Per Zone 3H A3H B3H 135F 135CS 135WP 200F 200CS 200WP 160EP 190EP 225EP 275EP 365EP 450EP 3T 11T 122 Unlimited Unlimited Unlimited Unlimited Unlimited Unlimited One 1 Per Zone 15 Per Zone 15 Per Zone NON SIEMENS FIRE SAFETY DETECTORS supports the following non SIEMENS detector brands Air Products and Controls Apollo BRK Refer to installation sheet or technical website for dd Contact on non Edwards Electro Signal Hochiki models Ratings CIRCUITS CURRENT DRAW STANDBY CURRENT 22.8 VDC zone max zone zone SUPPLY CURRENT BACK PLANE CURRENT SCREW TERMINAL CURRENT BACK PLANE CURRENT STANDBY 8mA zone max per zone 320mA zone max 280mA zone max max 8mA zone max 8mA per max 320mA zone max 280mA zone max Temperature and Humidity Range is UL Listed for dry within a temperature range of 49 2 to 32 3 0 2 a relative humidity of 93 2 at a of 90 3 32 2 for Ordering TYPE Card NOTICE The information contained in this data sheet document is intended only a summary and is subject to change without notice product s described here has have a specific instruction sheet s cover various technical limitation and liability information of install type instruction sheets as well as the General Product and Limitations document which also contains important data provided with the product and are available from the Manufacturer contained in the aforesaid type of documentation should be consulted a fire safety professional before specifying or using the product further questions or assistance concerning problems that might arise relative to the functioning of the equipment please contact Manufacturer Fire Safety Industry Inc Technologies Division Fernwood Road Florham Park NJ 07932 973 593 2600 2017 New Issue 0
