Siemens Cerberus PRO Intelligent Voice Communication, Data sheet

PRO Voice Communication fire protection system with voice evacuation Architect Engineer Specifications Powerful intelligent and user friendly fire and voice communication Model FV922 is the Cerberus PRO 252 point addressable voice communication system Model FV924 is the Cerberus PRO 504 point addressable voice communication system Voice systems exceed intelligibility requirements channel message player supporting 300 messages max Watts amplification per unit 3 simultaneous audio signals for each panel Communication with Cerberus PRO detection devices support of Advanced and Standard line of intelligent Models OOHC941 OOH941 OH921 OP921 and HI921 Gas Alarm events for CO detection per NFPA 72 Networkable fire and voice systems over CAT5 or fiber optic cables up to 32 fire and voice panels Uses voice over IP VoIP technology fire and voice signals sent over the same conductors Support of multiple command stations DMS Danger Management Station can monitor control up to 64 Model FV922 FV924 systems UL Listed for Fire UL 864 ULC S527 and Mass Notification 2572 ULC S527 in one 1 fire alarm control panel FACP event queues for MNS events MNS events can have higher and lower priority versus fire MNS events from devices on the addressable loop Supports pre action deluge and Sinorix agent release monitoring Supervision Supports multiple global display annunciators UL and ULC Listed FM CSFM and NYCFD Approved UL 464 Model FV922 FV924 systems meet the for low frequency signal tone 520 Hz as in the section for of Low Frequency Format in the Standard for Audible Signal Appliance used with an Amplifier Card or Booster Amplifier in with Siemens HiFi Speakers Speaker Strobes Series ceiling only appliances Supports built in TCP IP Connectivity Product Overview Voice Communication from Cerberus PRO Fire Safety advanced fire with voice system Through the use of its multiprocessor Network design along with its ability utilize detection devices Cerberus PRO a flexible and highly configurable fire protection with integrated voice evacuation a PRO voice panels are ideally suited for small and mid applications via each panel capability to provide up to Model FV922 and 504 Model FV924 addressable points with up to a 10,000 event history log Cerberus PRO fire protection system with voice capability easily accessible for operation push button soft keys a LCD screen and a 4 four way navigation push button all located in the upper portion on the panel front end PRO IVC panels are UL 10th Edition UL 1711 UL UL 2572 Listed ULC ULC S559 Listed in conjunction with Models FV924 is a new series of audible bases For example ABHW 4B is the first base its kind to attain agencies for its option to power from a signal line circuit in a two wire configuration when used with Cerberus PRO detectors for sleeping areas ABHW 4S generates a 520 square wave audio signal that with NFPA 72 Standard well as Underwriters applications PRO 252 504 Point Intelligent Voice System the Cerberus PRO Advanced and Standard line of detectors presents distinctive features and cost solutions that offer superior detection found in an of Siemens system applications related with the Advanced and Standard line High Sensitivity with Very Early Warning Fire Detection Carbon Monoxide CO Gas Detection and seven 7 heat detection temperature settings Infrastructure Building Products usa siemens com fire Data Sheet 9821 Cerberus PRO 252 504 point Fire Voice System Cerberus PRO Model FV922 252 point Model FV924 intelligent voice communication system is an control panel designed to meet the protection of mid size buildings advanced fire protection system with integrated voice offers features typically required in mid size in a package that is easy to install and competitively Additionally Models FV922 and FV924 are panels three height unit enclosure used exclusively with FV922 and FV924 The following components a complete three height unit 3HU enclosure Main System Components cont Boards Operating unit Standard type or light emitting diodes LEDs board power supply Main System Components Interface Unit Operating Interface Unit functions as the operator and central microprocessor for the Fire Terminal FT924 and Cerberus PRO FACPs Models FV922 and Model FCM2018 U3 the Standard Operating Unit or Model the Operating Interface Unit with LEDs each multi use capabilities events Quickly control the notification appliance circuits of the corresponding FACP a manual reset of the respective system information about the nature and location of the are displayed via a 2 4 3 4 5.1 cm 12.1 backlit liquid crystal display LCD screen Operating Interface Unit contains the site specific configuration created in the custom configuration tool Cerberus Works controller in each interface module provides all system and supervision Additionally the Operating Interface allow for connection to the Remote Peripheral Module FCA2018 U1 and or the Remote Terminal Displays FT2014 U3 R3 FT2015 U3 R3 For applications in Canada that require the use of a PRO operating unit with LEDs Model FCM2035 must be ordered periphery boards Models FCI2016 U1 and FCI2017 U1 integral components for operating the Cerberus PRO Models FV922 and FV924 Each module operates monitors input device identity as well as controls the circuits and other field devices i e C NET communicate with periphery board B Style Y or 1 Class A Style Z providing 24VDC nominal at a 5A per circuit maximum audible visual notification appliances equipped with periphery boards mount directly on the enclosure back of the Model FV922 and Model FV924 Cerberus PRO Models FCI2016 U1 FCI2017 U1 provide two 2 regulated 24VDC 1.5A max that supply power external devices or modules Supply Module Model 300 Watt power supply Model FP2012 U1 provides regulated 24VDC nominal power for normal to the Cerberus PRO 252 504 point addressable Filtered and regulated Model FP2012 U1 is rated Amps at 24VDC nominal 300 Watt power supply incorporates two 2
