PRO system Relay Card CRC 6 Architect Engineer Specifications Six 6 independent Form C double throw contacts Product Overview Controllable Relay Card Model CRC 6 which is used with the Cerberus PRO fire alarm control panels FACPs is designed to provide auxiliary control building functions door holder release elevator capture smoke control lock etc Model CRC 6 plugs into one 1 slot in the Model CC 5 or Model CC 2 Cage and provides six 6 fully programmable relays 4 Amps 30 VDC resistive 3.5 Amps 120 VAC 0.6 P F Fully programmable Time based operation Manual or automatic control Supervised coils Built in status and light emitting LEDs On board microprocessor UL864 CAN ULC S576 Listed CSFM NYC Fire Approved relay contains one 1 set of SPDT contacts rated at 4 30 VDC 120 VAC resistive and 3.5 amps 120 VAC 0.6 pF All relay coils are supervised to ensure operation Individual relays can be automatically or deactivated through control by event and logic contained in the Operator Interface OI may also be either controlled or Disarmed OI will indicate the affected relay and the Partial System indicator will illuminate until the relay is returned to Armed condition Model CRC 6 has on board LEDs for status and troubleshooting of power communication internal operation and power source are provided as well as indication of each operation and status for Model CRC 6 is performed using the Cerberus Modular systems software configuration tool ZEUS C Card Technologies Division Data Sheet 8314 Controls and Indicators SWITCH LED FAIL LED FAIL LED FAIL LED ACTIVE LEDs the Model CRC 6 card only system power is applied to Model CRC 6 when the card microprocessor has failed when the HNET communication fails the Model CRC 6 is in the DEGRADE mode when the 24 VDC supply falls below 18 VDC steadily to indicate the relay is active and blinks indicate relay coil failure There is one 1 LED for each of the six 6 relays for Ordering TYPE Card Ratings 20.5mA Active Relay CURRENT DRAW BACKPLANE CURRENT DRAW SCREW TERMINAL CURRENT DRAW STANDBY RELAYS 20.5mA Active Relay 30VDC resistive 120VAC 0.6PF Temperature and Humidity Range are UL 864 9th Edition Listed for dry locations within a temperature of 120 3 49 2 to 32 3 and a relative humidity of 93 2 a temperature of 90 3 32 2 NOTICE The information contained in this data sheet document is intended only a summary and is subject to change without notice product s described here has have a specific instruction sheet s cover various technical limitation and liability information of install type instruction sheets as well as the General Product and Limitations document which also contains important data provided with the product and are available from the Manufacturer contained in the aforesaid type of documentation should be consulted a fire safety professional before specifying or using the product further questions or assistance concerning problems that might arise relative to the functioning of the equipment please contact Manufacturer PRO Industry Inc Technologies Division Fernwood Road Florham Park NJ 07932 973 593 2600 2017 New Issue 0
