Siemens Desigo Intelligent Voice Communication (system overview), Data sheet

Fire Safety Voice Communication fire protection system with voice evacuation Architect Engineer Specifications Powerful intelligent and user friendly fire and voice panel Model FV2025 is the Desigo 252 point addressable intelligent Model FV2050 is the Desigo 504 point addressable intelligent communication system communication system Voice systems exceed intelligibility requirements channel message player supporting 300 messages max Watts amplification per unit 3 simultaneous audio signals for each panel Communication with Desigo detection devices support of Advanced and Standard line of intelligent Models FDOOTC441 FDOOT441 FDOT421 FDT421 and FDO421 Gas Alarm events for CO detection per NFPA 72 Networkable fire and voice systems over CAT5 or fiber optic up to 32 fire and voice panels voice over IP VoIP technology fire and voice signals sent over the same conductors Support of multiple command stations CC Danger Management Station can monitor and up to 64 Model FV2025 FV2050 systems UL Listed for Fire UL864 ULC S527 and Mass Notification ULC S576 in one 1 fire alarm control panel FACP Supports pre action deluge and Sinorix agent release Supports multiple global display annunciators UL and ULC Listed FM CSFM and NYCFD Approved event queues for MNS events monitoring Supervision MNS events from devices on the addressable loop MNS events can have higher and lower priority versus fire UL464 Model FV2025 FV2050 systems meet the for low frequency signal tone 520 Hz as in the section for of Low Frequency Format in the Standard for Audible Signal Appliance used with an Amplifier Card or Booster Amplifier in with Siemens HiFi Speakers Speaker Strobes Series ceiling only appliances Supports built in TCP IP Connectivity a Product Overview Fire Safety Intelligent Voice Communication IVC from advanced Fire Safety unit Through use of Network design as well as with with intelligent detection devices Desigo IVC system flexibility Desigo IVC panel is easily accessible for operation soft key a backlit liquid crystal display LCD screen and a four way navigation push button are all located in the upper of each FACP front end IVC which provides up to 252 via Model FV2025 and via Model FV2050 networkable addressable points UL 864 10th Edition UL1711 UL2017 UL2572 Listed ULC ULC S559 Listed Models FV2025 FV2050 as well as Booster Amplifier have been seismic qualified with International Building Code 2012 California Code 2013 ASCE 7 2010 Chapter 13 OSHPD CAN 2 Rev 2 effective 10 31 08 and revised 6 26 09 ICC AC 156 Approved October 2010 and Effective November IVC panels also meet the UL464 requirement for 520 Hz signal tone when used in conjunction with HiFi speakers speaker strobes and ceiling appliances in correlation to Desigo IVC are an original series of sounder bases Model is the first ever base to agencies approval for its to power directly from a line circuit SLC in a two configuration when Model used with Desigo detectors areas ABHW 4S generates a 520 square wave audio signal complies with NFPA 72 as well as Underwriters applications 252 504 Point Intelligent Voice System Infrastructure Building Products usa siemens com fire Data Sheet 6821 Product Overview cont Models FV2025 and FV2050 are compatible the Desigo CC Fire Management Station which is easy and provides optimized monitoring and control of building automation and systems For each Desigo CC station monitors controls up to 63 MXL nodes 32 Desigo Fire Safety nodes Apogee Automation panels and up to 20,000 Desigo detection devices Desigo 252 504 point Fire Voice System Desigo Model FV2025 252 point Model FV2050 504 an control panel designed to meet the protection of mid size buildings advanced fire protection system with integrated voice offers features typically required in mid size in a package that is easy to install and competitively Additionally Models FV2025 and FV2050 are panels three height unit enclosure is used exclusively with Models and FV2050 The following components comprise a three height unit 3HU enclosure voice communication Operating unit Standard type or light emitting diodes LEDs board power supply Main System Components Interface Unit Model Operating Interface Unit functions as the operator and central microprocessor for the Fire Terminal FT2050 and Desigo FACPs Models FV2025 and FCM2018 U2 Standard Operating Unit or FCM2019 U2 Operating Interface Unit with LEDs provides multi use capabilities events Quickly control the notification appliance circuits of the corresponding FACP a manual reset of the respective system information about the nature and location of the are displayed via a 2 4 3 4 5.1 cm 12.1 backlit liquid crystal display LCD screen Operating Interface Unit contains the site specific configuration created in the custom configuration tool Works and can be configured as a network display controller in each interface module provides all system and supervision Additionally the Operating Interface allow for connection to the Remote Peripheral Module FCA2018 U1 and or the Remote Terminal Displays FT2014 U2 R2 FT2015 U2 R2 The system up to 10,000 event history event log System Components cont For applications in Canada that require a Desigo unit with LEDs Model FCM2035 U2 must be Boards periphery boards Models FCI2016 U1 and FCI2017 U1 integral components for operating the Desigo panels FV2025 and FV2050 Each module operates and as well as controls the circuits communicate with and other field devices i e FDnet periphery board B Style Y or 1 Class A Style Z providing 24VDC nominal at a 5A per circuit maximum audible visual notification appliances equipped with periphery boards mount directly on the enclosure back of the Model FV2025 and Model FV2050 Desigo Models FCI2016 U1 FCI2017 U1 provide two 2 regulated 24VDC 1.5A max that su
