Siemens FC901 fire control panel

FC901 U3 FC901 R3 addressable Signaling Line Circuit SLC which can be configured as one A Style 6 or 7 or two Class B style 4 addressable point capacity system easy to use programming capabilities Field Programmable Via Windows Laptop Computer or by the FACP directly dots LCD display User friendly system interface AC power input 120 240VAC 50 60Hz amps of system power Relays alarm trouble supervisory programmable insensitive detection circuits Patented one Class A or two Class B SLC FirePrint application specific detection Sensitivity Readout Printout per NFPA 72 Character Custom messages Command Stations Event History Logging with On Line Off Line Reports Levels of Password Protection verification by Device or Zone Technologies safety and security products inhibit timer silence timer supported Controlled Output Functions Tie Leased Line DACT digital alarm communicator transmitter two Notification Appliance Circuits NACs rated at 2.5 amps with up to 2.5 24VDC per NAC NAC can be configured as style Y class B or style Z class A strobe synchronization protocol Pre signal and PAS Single Person Quick Test interface for local upload download FC901 is a compact but powerful standalone fire alarm control panel It features addressable fire detection keypad and offline programming notification circuits 160 by 64 dots LCD display and event history retention capability Its typical includes a power supply a signaling addressable device circuit two appliance circuits NAC Digital Alarm Communication Transmitter DACT system status relays and a USB programming port All the components of the FC2005 panel are mounted in an 18.1 x 16.5 enclosure main board FC901 has only one electronic main board which integrates most functional parts the CPU board is mounted to main board before delivery including DACT Display signaling line circuit NAC serial interface circuits system status relays port and battery charging circuit The main board is mounted on the frame and it provides the connections for external field wiring An optional city module can be mounted on the backside of the main board The power supply is under the main board and supporting frame Technologies safety and security products Supply FP2011 U1 26V nominal power supply provides all operating power to the control panel for both and alarm conditions Sufficient battery charging capability is available to charge AH sealed lead acid batteries within code requirements for up to 24 hours of normal operation plus 5 minutes of alarm operation The battery will be automatically at low battery voltage to prevent deep discharge and battery damage the components of the FC901 control panel are mounted in an 18.1 x 16.5 enclosure supports surface mounting and semi flush mounting Semi flush mounting kits are for the enclosure enclosures must be fastened securely to a clean dry shock free and vibration free in a protected environment Technologies safety and security products Tie Module city tie module provides local energy and polarity reversal connections The polarity connections provide a trouble circuit and an alarm circuit with optional trouble The city tie board mounts onto the main board Information Cerberus main board Cerberus housing black Cerberus housing red Cerberus configuration kit Configuration cable Housing trim kit black Housing trim kit red Battery bracket No Siemens Cerberus Electronics Limited Xibeiwang HaiDian District 100094 China 10 6476 8806 10 6476 8899 No a Data and design subject to change without notice
