Siemens FPT-11 Intelligent Thermal Detector, Data Sheet

Sheet Safety Security Products Detection Devices Thermal Detector use with FireFinder XLS and MXL Panels FPT 11 AND ENGINEER SPECIFICATIONS Innovative technology provides high speed system detector Compatible with Model DPU or FPI 32 programmer tester Multi color detector status diode LED Optional fully programmable relay audible bases FM CSFM NYCFD Approved UL and ULC Listed Overview Intelligent Thermal Detector Model FPT 11 from Fire Safety provides an advanced method of address programming and supervision with sophisticated fire alarm control panel communication Model FPT 11 uses a state of the thermistor that provides up to 135 57.2 rate temperature FPT 11 is compatible with Model DPU and FPI 32 Programmer Testers which are compact portable menu driven accessories that make programming testing detectors faster easier and more reliable other methods of these field programmers testers eliminate the for cumbersome unreliable mechanical methods and they reduce installation and costs via electronically erasable programmable memory EEPROM and can test Model FPT 11 for proper function before the detector is installed Moreover mechanical addressing such as program jumpers DIP switches or dials are no longer necessary to use Industry Inc Technologies Division Microprocessor based design Two wire operation Rate compensated FPT 11 is a plug in two wire thermal detector that is with FireFinder XLS and MXL FACPs Each FPT 11 detector has microcomputer chip as well as highly stable solid state electronic FPT 11 utilizes a modern accurate and shock thermistor to sense temperature changes This sensing method virtually eliminates thermal lag with mechanical temperature sensing devices provides almost instantaneous temperature to the FACP FPT 11 is a 135 57.2 rate compensated The microprocessor for Model FPT 11 detector the EEPROM means to store the detector address within the detector as well as between FPT 11 the FACP or with each field programmer are supervised and safeguarded against disruption reliable microprocessor based error checking routines the microprocessor supervises all EEPROM locations and provides a high tolerance to faults Thermal Detector 6176 continued FPT 11 is UL and ULC Listed as a self testing device visible LED from Model FPT 11 flashes green every four to indicate Model FPT 11 is communicating with the as well as to signify Model FPT 11 successful passing its self test Should the detector sense a fault or failure its systems the LED will flash amber and the detector transmit the fault or failure back to the FACP quick visual inspection is sufficient to indicate the condition the detector at any time If more detailed information is a printed report can be provided from the FACP the status and settings assigned to each individual Model FPT 11 moves to the Alarm mode Model FPT 11 flash amber and will transmit data to the FACP When FACP confirms the current condition of Model FPT 11 the will instruct Model FPT 11 detector to flash red until the is reset at the FACP At that same time any user system alarm functions programmed into the XLS or MXL system are activated Each Model detector can operate one 1 remote alarm indicator 1 auxiliary relay or one 1 audible base and only one accessory per detector DPU or Model FPI 32 is used to program and verify the for Model FPT 11 The end user selects the Program to enter the desired address Then the programmer automatically sets and verifies the address as well as the detector The programmer tester contains batteries in order for the address of Model FPT to be programmed by the end user from a portable The user can also separately test the Model FPT 11 for functionality the end user selects the mode a series of tests are conducted and the user is informed whether FPT 11 detector has passed or failed FPT 11 detector is compatible on the same circuit with other Model IL series Model FP series or ID 60 series addressable ionization photoelectric or detectors Model MSI addressable manual stations TRI series addressable interfaces or Model CZM series conventional zone modules Model FPT 11 is capable of operating one 1 or remote alarm indicator or auxiliary relay or audible FPT 11 detectors use a surface mounting base Model which mounts on a 4 inch octagonal square or single electrical box Relay base Model DB X11 RS mounts to a square deep electrical box Audible base Model ADBX also mounts to a 4 inch square deep electrical box DB 11 DB X11 RS and ADBX 11 use screw clamp for all electrical connections and self wiping for reliability The bases also contain a provision an optional concealed locking mechanism to prevent removal of the detector head Model LK 11 Data XLS uses Model MLC but the MXL FACP uses ALD with each respective circuit capable of up to 60 Model FPT 11 intelligent detectors detector or group of detectors require a minimum circuit of 18 American Wire Gauge AWG wire enclosed in conduit or a 18 AWG limited energy shielded cable without per local building codes Wiring should conform local and national electrical codes as well as the wiring of the FACP is permitted only Class B Style 4 wiring Model FPT 11 on the ceiling at least 4 inches from side walls For an ideal smooth ceiling condition the detectors at a maximum center spacing of 50 2,500 square feet 25 feet from side walls or room For FM Approved installations Model FPT 11 a relative temperature index RTI rating of a maximum center spacing of 20 feet 400 square 10 feet from side walls or room partitions job conditions and sound engineering judgment determine detector spacing Be sure to consider factors including ambient temperature and the nature of the fire hazard Room or configuration and ceiling type sloped or flat smooth beamed also dictates placement questions arise regarding detector placement the drawings provided and or approved by Fire Safety or by its authorized distributors Data Requirements 750 750 Temperatures 0 to 49 Humidity Non condensing Industry Inc Technologies Division Diagram for Ordering 500 096181 Audible Base for Series 11 Detectors Mounting Base for Series 11 Detectors Small 4.5 Inch Diameter Detector Base 500 094187 Base Adapter to Model DB 3S Base 500 096125 Relay Base for Series 11 Detectors Addressable Thermal Fire Detector Base Locking Kit for Series 11 Detectors Remote Alarm Indicator mount red Remote alarm Indicator box mount red Canada order 500 096181C 500 096125C Base for Series 11 Detectors ULC Mounting Base for Series 11 Detectors ULC Base for Series 11 Detectors ULC Thermal Fire Detector ULC Industry Inc Technologies Division This marketing data sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division
