Siemens FT2007-U1 Desigo LED Annunciator Driver, Data sheet

Fire Safety Annunciator Driver FT2007 U1 LED Annunciator Driver Model FT2007 U1 from Siemens Fire Safety is the component for custom graphic annunciators on addressable Desigo panels optional system module provides outputs for system status as well as zone Model FT2007 U1 is supervised via a built in RS interface A maximum 8 modules are allowed on each RS communication bus Provides 96 light emitting diode Architect Engineer Specifications outputs for up to 32 zones separate Alarm and Trouble outputs zone Contains 16 programmable inputs one 1 key switch Key switch is positioned from 17th input at all times Displays seven 7 system status Power ON Trouble Ground Audibles ON Silence and The first LED is always Power Supervised via a RS bus Maximum eight 8 modules on each RS Set address and Baud Rate via DIP switches Requires external 24 Volts DC UL 864 10th Edition and ULC S527 FM 3010 Approved Product Overview LED Annunciator Driver Model FT2007 U1 from Siemens Fire Safety is main component for custom graphic annunciators on addressable Desigo This optional system module provides outputs for system status as well zone status Model FT2007 U1 is supervised via a built in RS interface maximum eight 8 modules are allowed on each RS communication Specifications FT20007 U1 is designed for use in custom graphic annunciators Model are 16 inputs to accommodate user defined system commands which Reset Silence Unsilence Acknowledge and Lamp Test can also be programmed as which allows additional flexibility customized functionality Model FT2007 U1 also includes 96 highly outputs to drive LED indicators annunciator driver is operated as a remote graphics display indicator at a of up to 3,281 ft 1,000m from a Desigo FACP FT2007 U1 gets its operating power from either the auxiliary power from a Desigo addressable control panel Model FC901 or from a UL Listed 24VDC power supply shipment of the LED Annunciator Driver includes two 2 PC boards one 1 built in RS interface and one 1 LED driver Additionally 1 ribbon cable is packaged allowing connectivity between the two 2 A system enclosure or display panel must be ordered separately The user needs to provide the cable between the Molex connector and the system LEDs switches Infrastructure Building Products usa siemens com fire Data Sheet 6824 Temperature and Humidity Range FN2001 U1 is UL 864 10th Edition Listed for indoor locations within a temperature range of 120 3 to 32 3 0 2 and a relative humidity of at a temperature of 90 3 32 2 Data Inputs Operating Voltage 24VDC nominal Current Current 30 VDC Documentation Sheet 50 point addressable FACP 252 point 504 point FACP Intelligent Communication IVC for Ordering RS 485 Annunciator Driver Design Admissible cross section 18 28 AWG Wire Gauge connection via four ribbon cables included Properties and Outputs Location Temperature Temperature dry 120 49 140 60 95 relative Properties W x H x D 4.3 x 6.0 x 1.2 cm 11.0 cm x cm x 3.0 cm Lb 454g includes One 1 ribbon cable connection between PCBs One 1 end of line EOL jumper Three 3 plastic cable ties Four 4 connectors for interface ribbon cables not Ten 10 hexagonal with mounting For applications in Canada the Model FT2007 U1 LED Driver is used optionally in the provinces and can be utilized to display system status in real time order to comply with ULC regulations each LED Annunciator must be housed in a lockable ULC S527 Listed enclosure NOTICE The information contained in this data sheet document is intended only a summary and is subject to change without notice product s described here has have a specific instruction sheet s cover various technical limitation and liability information of install type instruction sheets as well as the General Product and Limitations document which also contains important data provided with the product and are available from the Manufacturer contained in the aforesaid type of documentation should be consulted a fire safety professional before specifying or using the product further questions or assistance concerning problems that might arise relative to the functioning of the equipment please contact Manufacturer Fire Safety Industry Inc Infrastructure Building Products Fernwood Road Florham Park NJ 07932 973 593 260 2021 4
