Siemens IIC Desigo Modular Interface Isolation Card, Data Sheet

Fire Safety system Isolation Card IIC Architect Engineer Specifications Isolates the respective card from the HNET network Backplane network signals are from each Model CC 2 cage to create the isolation Product Overview Interface Isolation Card Model IIC is designed to isolate network on a Desigo Fire Safety Modular control panel when used with a fire center FCC ring configuration via Model NRC IIC executes the aforementioned isolation by removing the backplane signals from each Model CC 2 card cage Model IIC also provides 1 end of CAN termination on each side of Model CC 2 Provides one end of termination on the of Model CC 2 Designed for use in a Model with Reg Approval ring configuration via with Reg Approval NRC with Reg Approval UL864 CAN ULC S527 Listed Specifications Interface Isolation Card which operates through the use of a FCC and Model VNT series device in unison is used to isolate the signals in a ring a 2nd generation Network Ring Card Model NRC IIC plugs into a 60 pin connector on the second and Model CC 2 card cages contained in each enclosure The male ribbon cable data from the cable of the Model CC 2 card cage The receptacle into the 60 pin receptacle of next in line Model CC 2 card cage Plugs into a 60 pin connector 2 60 pin interfaces are contained in each Model IIC Technologies Division IIC Card Data Sheet 7356 usa siemens com desigo fire safety Ratings Model PSC 12 serves as the source main power supply and P2 in the power limited Model CC 2 card cage total rating on P1 and P2 loops for all two slot cages in a given Siemens enclosure is as follows CURRENT DRAW CURRENT DRAW max max for Ordering NUMBER Card NOTICE The information contained in this data sheet document is intended only a summary and is subject to change without notice product s described here has have a specific instruction sheet s cover various technical limitation and liability information of install type instruction sheets as well as the General Product and Limitations document which also contains important data provided with the product and are available from the Manufacturer contained in the aforesaid type of documentation should be consulted a fire safety professional before specifying or using the product further questions or assistance concerning problems that might arise relative to the functioning of the equipment please contact Manufacturer Fire Safety Industry Inc Technologies Division Fernwood Road Florham Park NJ 07932 973 593 2600 2017 New Issue 0
