Siemens MH Notification Appliances Mini Horn Appliances, Data Sheet

Catalog Series Notification Appliances Mini Horn Appliances Indoor Overview Field selectable settings for Temporal Code 3 or Continuous Horn Siemens Series MH piezoelectric Mini Horns are compact electronic alarm appliances that listed under UL Standard 464 for Audible Appliances in Public Mode Fire Protection Systems Can be synchronized using the Siemens DSC sync modules FS 250 panel XLS panel or PAD 3 supply with built in sync protocol Designed to meet or exceed NFPA ANSI standards Convenient mounting to any standard single gang box Plugs to cover mounting screws No additional trim plate required for flush mounting Fast installation with In Out screw terminals using 12 to 18 AWG High sound output with low current draw Available in color red or white front Applications individual rooms apartments hotels motels offices Listed ULC Listed CSFM NYMEA Approved Notification appliance shall be a Siemens MH or approved equal Notification appliance shall be electronic and shall have field selectable settings for Code 3 or continuous horn and support coded systems operation The anechoic ULC only sound pressure measurement on Temporal Code 3 and Horn settings shall each be 87 dBA Anechoic minimum at 24VDC All models shall have provision for standard reverse polarity type supervision and In Out using terminals that accept 12 to 18 AWG wiring The appliances shall be mounted indoors and mount on standard single gang electrical All notification appliances shall be listed for Applications boxes requiring no additional trim plates or adapters Industry Inc Technologies Division Series Notification Appliances 2575 Diagram Mounting Options Shown In Inches Data Details for Ordering Including Mounting Options Agency Approvals Mini Horn Appliance Red Mini Horn Appliance White listed approved Refer to catalog sheet 2585 for detailed mounting options X X Approvals ULC FM CSFM This marketing catalog sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www SBT Siemens com FIS in U S A Safety Kenview Boulevard Ontario 5E4 Canada 905 799 9937 905 799 9858 2009 sheet dated 7 07 1
