Installation Instructions MOM2 XMP Mounting Plate Model MOM2 XMP Mounting Plate from Siemens Industry Inc is used in CAB2 CAB3 enclosures for mounting MOM 2 modules A MOM2 XMP in one position on a CAB MP system mounting plate Enclosure is for indoor use only in dry environments all system power before installation first battery then AC To power up the AC first then the battery to Figure 1 is a top and bottom to the MOM2 XMP Mounting The top end is the end with the longer 17 8 cutout With the top end of the MOM2 XMP facing up the MOM 2 on the plate with the terminal TB4 TB2 of the MOM 2 on the right side in place with two of the 10 32 screws in the upper and lower threaded holes the plate MOM2 XMP can be installed in any one of four mounting positions on the CAB MP consideration should be given to wiring If the terminal blocks of the will be utilized it is best to place the in position 4 of the CAB MP See 2 the MOM2 XMP to the CAB MP with of the 10 32 screws in the top threaded and two of the 10 32 screws in the threaded posts of the CAB MP OF 1 The MOM 2 The MOM2 XMP MOM2 XMP can be used in CAB1 CAB2 and CAB3 enclosures Mounting Plate 4.75 x 17 315 034822 3 Industry Inc Technologies Division 1 2 3 4 THREADED POSTS THREADED POSTS 1 2 3 4 2 Mounting Positions Industry Inc Technologies Division Park NJ Building Technologies Ltd Safety Security Products Kenview Boulevard Ontario 5E4 Canada 315 034822 3
