Siemens MTE-2 Enclosure Assembly, Installation Instructions

Installation Instructions MTE 2 indoor use only in dry environments Model MTE 2 from Siemens Industry Inc an enclosure assembly that accommodates to six remote telephones the enclosure securely to a clean dry and vibration free surface Con the following when mounting the box height for visual and manual to the telephones in the enclosure location that provides easy access to remote telephone jacks and size of the enclosure mounting codes mounting position the backbox clear of so that the door can open freely so that the contents are easily accessible INSTALL THE MTE 2 Slip the door off the hinges of the box and it to one side temporarily Cover the opening in the door by placing clear lens over the studs on the door Fasten the lens to the door using the six nuts provided to Figure 1 Place the telephone plate over the standoffs marked A near the top of the enclosure 5 Fasten the plate to the standoffs using the 4 40 x 1 4 screws provided 6 Hold the empty enclosure against the wall a height that provides easy access 1 for the MTE 2 Industry Inc Technologies Division Park NJ 315 093304 5 Building Technologies Ltd Safety Security Products Kenview Boulevard Ontario L6T 5E4 CN 7 Mark drill points on the wall in the center of two slots on the upper rear of the box 9 Mount the enclosure on the two screws and install the bottom screws 8 Drill the two holes and screw in the top Tighten all screws securely against the back using 1 4 or 3 8 mounting hardware supplied Leave a small gap between wall and each top screw of the enclosure Slip the door back on the hinges of the 315 093304 5
