Siemens MXL – Simplex Service Manual

SERVICE Series Division Siemens Control Panel Advanced fire protection control panel Multiplexed Alarm Reporting Custom Site Specific Custom Programming Basic Panel Contains Two Addressable Loop Two NAC Circuits Three System Relays Alarm Trouble Supervisory Additional MOM 4 Motherboard Additional System Modules Input or Control Outputs Series Addressable System System with Integrated Voice Features MXL system with Limited Point Capacity MXL MXLV MXL IQ Network of the above systems can be Integrated into a Network Configuration Back Box Tan 1 2 MMB 1 Main Control Board 2 Addressable Loops Devices 2 NAC Circuits Amps Each MOM 4 Motherboard 4 Half Width Modules 2 Full Width Modules Capable of Holding 2 Modules 2 Addressable Loops per Each 240 Devices Total TSP 40 Thermal Strip Printer Configuration Back Box Tan 1 2 MMB 1 Main Control Board 2 Addressable Loops Devices 2 NAC Circuits Amps Each 2 MOM 4 Motherboards 8 Half Width Modules 4 Full Width Modules Capable of Holding 2 Modules 2 Addressable Loops per Module 480 Devices Configuration Back Box Black HOLD 1 ALT 2 MMB 1 2 Main Control Board 2 Addressable Loops Devices 2 NAC Circuits Amps Each 2 MOM 4 Motherboards 8 Half Width Modules 4 Full Width Modules Capable of Holding 2 Modules 2 Addressable Loops per Each 480 Devices Total TSP 40 Thermal Strip Printer Configuration Back Box Black HOLD 1 ALT 2 MMB 1 2 Main Control Board 2 Addressable Loops Devices 2 NAC Circuits Amps Each 3 MOM 4 Motherboards 12 Half Width Modules 6 Full Width Modules Capable of Holding 2 Modules 2 Addressable Loops per Module 720 Devices Control Panel Continuous System Supervision Microprocessor Based Polling System Degrade Operation Enhances system reliability in case of main CPU failure System Outputs Programmable Output Operation Cabinet Mounted Outputs Addressable Filed Devices with Control Capability System Components MMB 1 2 Main System Board MPS 6 12 Power Supply MKB 1 Keyboard Annunciator TPS 40 Strip Printer MBR 1 box MDR 1 MDR 1P Door Plain or with Printer View port Batteries Main System Board 16 bit CPU with EPROM RAM Memory Storage Watchdog circuitry for CPU Operation Flash memory for the CSG M System Specific Program Network Interface for Transponders or Peer to Peer Operation Back Up Battery Capability up to 60 Amp Hours 24VDC Regulator for Internal System Power Requirements Field Power is Unfiltered with Minimal Rectification AC Transfer Relay for Continuous Operation Main System Board Class A Power for CZM 1 Field Modules 24 VDC unregulated supply Two Analog Loops and Control Devices on the Same Loop Two Indicating Appliance Circuits Class A or Class B Operation Three Form C Relays Alarm Trouble and Supervisory Power Supplies MPS 6 Power Supply Supervised power supply 6.5 Amp 24 VDC unregulated output MPS 12 Power Supply Supervised power supply 12.5 Amp 24 VDC unregulated output Transponder Power Supply Keyboard Annunciator 00 00 JAN 01 1990 CERBERUS PYROTRONICS SYSTEM MXL NORMAL 1 2 Keyboard Annunciator Annunciator and manual control panel for the MLX 2 line 80 character alphanumeric display System Indicators Power indicator Green Alarm indicator Red Audibles silenced Red Supervisory indicator Yellow Trouble indicator Yellow Security indicator Yellow Point disabled Yellow Keyboard Annunciator The Keypad contains the following keys ACKnowledge AUD SIL Audible Silence RESET NEXT display HOLD display Numeric keys Cursor Controls PRINT HELP and CLEAR keys User configurable function keys Keyboard Annunciator MKB 1 MXL Display Keyboard unit is used on the original version of the MXL system GREY The display mounts with stand off legs to bolts on the back of main backbox MKB 2 MXL Display Keyboard Hinged unit is used on the current version of the MXL system BLACK The display is hinged for wiring access MKB 3 MXL Display Keyboard for 19 Rack Mounting unit is used when the MXL system is installed in a Rack mount For this configuration the MKB RK Rack Mount Bracket must used MKB 4 MXL Display Keyboard Hinged for IQ unit is used on the MXL IQ system The display is also used with the system upgrade kit to a MXL system configuration Thermal Strip Printer Located within the Cabinet Back Box System Connections NOT Supervised Supervised Through Power Connection Provides paper record of the activity of the system Historical Logging All Events System Modules MMB 1 2 Main System Board MOM 2 4 Motherboard Card Cage CSM 4 Signal Module CRM 4 Relay Module CZM 4 Conventional Zone Module ALD 2 2I Analog Loop Driver XLD 1 Analog Loop Driver XL3 Devices PSR 1 Remote Power Supply Communicating Modules RCC 1 1F Remote Command Center NET 4 7 Communication Interface NET 7M Communication Interface NIM 1R Network Interface Module REP 1 Network Repeater Module PS 5N7 Network Interface 5V Power Supply MOI 7 Voice and Annunciator Driver MOD 16 Output Driver MID 16 Input Driver System Modules CMI 300 Interface Module ACM 1 Audio Control Module TMM 1 Telephone Master Module MMM 1 Microphone Master Module VSM 1 Voice Switch and LED Module VLM 1 Voice LED Module VFM 1 Fan Control Module TBM 2 Termination Block Module OMM 1 2 Output Master Module System Modules ASC 1 Amplifier Supervision and Backup Card ASC 2 Amplifier Riser Supervision and Backup Card OCC 1 Output Control Card BTC 1 Backup Tone Card RCM 1 Riser Control Module ZAC 30 Zone Amplifier Card DMC 1 Digital Message Card ZC Zone Control Card Modules Series of Output Cards ZCT 8B Zone Card Telephone CARD CAGE Contains four option slots Four half width cards Two full width cards Two power connectors Two data connectors MXL system can accommodate up to two MOM 4 card in a single enclosure As long as there is no Printer installed Signal Module SIGNAL MODULE CSM 4 APPLIANCE CIRCUITS 2 STYLE Y OR STYLE Z CIRCUITS 1.5 AMPS EACH MARCHTIME TEMPORAL CODED OUTPUT CONFIGURABLE FOR CITY CONNECTION SILENCEABLE OR NON SILENCEABLE PROGRAMMABLE DEGRADE OPERATION 2 OPEN COLLECTOR OUTPUTS DIAGNOSTIC USE
