Siemens NH NS - NH Notification Appliances Horn and NS Horn Strobes, Data Sheet

s Sheet Safety Products Appliances NS NH Horn and NS Horn Strobes Indoor Overview installation with In Out screw terminals using 12 to 18 AWG wires can be synchronized using the Siemens DSC sync modules the Siemens 50 point and 504 point fire alarm control panels FACPs as well as with XLS and MXL FACPs or PAD 4 NAC Extenders with built in sync protocol Continuous Horn or Temporal Code 3 models are available with field selectable Candela settings and 115 177cd Listed 3150 and CSFM Approved 7125 0067 0248 Fire Alarm Devices For The Hearing Impaired NFPA UFC ANSI compliant with OSHA 29 Part 1910.165 visual notification appliances are Siemens Series Horn Strobe appliances and Horn appliances or approved equals series of appliances meets UL Standard 1971 Devices for the Hearing Impaired for Indoor Fire Protection Service series of Horn appliances is UL Listed under Standard 464 Fire Protective Signaling series of Horn Strobes is UL Listed for indoor use only inputs are compatible with standard reverse polarity supervision of circuit wiring by Siemens Fire Alarm Control Panel FACP audible portion of the appliance has a minimum of two 2 field selectable settings for levels and has an audio output of either continuous or Temporal Code 3 pattern strobe portion of the appliance produces a flash rate of one 1 flash per second over the Regulated Voltage Range and incorporates a Xenon flashtube enclosed in a rugged Lexan lens series of appliances is of low current design intensity where ceiling mount multi Candela appliances are specified is easily controlled field selectable settings and is rated per UL Standard 1971 for 15 30 75 95cd 115 117cd Industry Inc Technologies Division NS Series Notification Appliances 2577 continued The switch used for selecting the Candela setting is tamper resistant When synchronization is required the appliance is compatible with Siemens DSC Sync Modules the 50 point 252 point and 504 point fire alarm control panels FACPs as well as with FireFinder XLS and MXL FACPs PAD 3 or PAD 4 NAC Extenders with built in sync protocol The strobes will not drift out of synchronization at any time during operation The strobes will revert to a non synchronized flash rate if the sync module or Power Supply fail to operate i e contacts remain closed The appliance is also designed so that the audible signal may be silenced while maintaining strobe when used with Siemens synchronization The Series Horn and Horn Strobes of appliances incorporates a Patented Universal Mounting that will allow mounting to a single gang double gang 4 inch square 10 cm European type or the SHBBS Surface Backbox For use where required an NATP Notification Appliance Trim Plate is provided All notification appliances are listed for Special Applications Strobes are designed to flash at 1 flash per second minimum over their Input Voltage Range Note NFPA 72 specifies a flash rate of 1 to 2 flashes per second and ADA Guidelines a flash rate of 1 to 3 flashes per second All Candela ratings represent minimum effective Strobe intensity based on UL Standard 1971 The Series Horn Strobe of appliances is UL Listed under UL Standard 1971 for indoor use a temperature range of 32 to 120 0 to 49 and maximum humidity of 93 2 The Series Horns of appliances is UL Listed under UL Standard 464 for audible signal appliances Indoor use only Diagram Shown In Inches Options Industry Inc Technologies Division Data Series Ceiling Mount Voltage Special Application Voltage 16.0 33.0VDC 16.0 33.0VRMS UL 464 and NS HMC C Series Ceiling Mount Ratings AMPs Voltage RMS Current with Hi dBA Setting 30cd 75cd 95cd 115cd 177cd 16.0 33.0VDC 0.087 0.130 0.222 0.292 0.371 0.506 16.0 33.0VRMS 0.150 0.216 0.331 0.411 0.521 0.722 Ratings AMPs Voltage RMS Current with Low dBA Setting 30cd 75cd 95cd 115cd 177cd 16.0 33.0VDC 0.075 0.121 0.213 0.277 0.324 0.499 16.0 33.0VRMS 0.488 0.195 0.319 0.421 0.497 0.705 Series Series Series Ceiling Mount Sound Output Per UL 464 VDC 24.0 VDC 33.0 VDC 3 Horn March Time Available only in sync mode Series Ceiling Mount Sound Output Per UL 464 VDC 24.0 VDC 33.0 VDC 3 Horn March Time Available only in sync mode NH C Audible Appliances are UL Listed to operate over a Voltage Range Limit from 16.0VDC to 33.0VDC 24VDC applications using filtered DC or unfiltered Full Wave Rectified FWR input voltage 1 NS Strobe will produce 1 flash per second over the Input Voltage range This horn strobe model meets the required light distribution patterns defined in UL 1971 All models are UL Listed for indoor ceiling use with a temperature range of 0oC to 49oC to 120o F and maximum humidity of 93 2 RH effect of shipping and storage temperatures shall not adversely affect the performance the appliance when stored in original cartons and is not subjected to either misuse or handling of shipment Industry Inc Technologies Division for Ordering Including Mounting Options Agency Approvals 15 30 75 95 NS Strobe Multi Candela Red 15 30 75 95 NS Strobe Multi Candela White NS Strobe Hi Multi Candela Red NS Strobe Hi Multi Candela White Horn Red Horn White Approvals CSFM Refer to data sheet 2585 detailed mounting options Agency Listed Approved This marketing data sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www usa Siemens com Fire in U S A Safety North Service Road Oakville Ontario 0H6 Canada 905 465 8000 www Siemens CA 2015 sheet dated 12 09 2
