Siemens NIM-1W NIM-1M MXL Long Distance Communication Bridge, Data Sheet

Data MXLV Long Distance Communication Bridge NIM 1M NIM 1W AND ENGINEER SPECIFICATIONS MXL LifeLINK wide area network WAN module Extends MXL communication distance for each system as well as between MXL networks Unlimited communication distance between MXL IQ or MXLV systems when a line that is conditioned for 19.2K rate is used Up to 8 miles on dedicated 18 AWG copper wire Supports standalone and network MXL Instant monitoring and controlling capabilities remote MXL panel s Nine 9 communication status light emitting LEDs Model NIM 1M Supports full inter panel logic Compatible with OS 2 and Windows NT Network Command Center NCC UL 864 9th Edition Listed and ULC Listed Overview NIM 1W is a Siemens Industry Inc Fire Safety network interface module that communicates system information to an on board analog modem NIM 1M which is a daughter board that directly onto Model NIM 1W module When NIM 1M is connected to Model NIM 1W MXL information can be transmitted over dedicated telephone wires NIM 1M can transmit MXL system s information dedicated telephone wire 18 26 AWG and or a line conditioned for 19.2K baud rate allowing MXL communication distances to be extended NIM 1W NIM 1M communicates with other NIM 1M thus forming a long distance bridge that can interconnect a single or local MXL network with a remote network and single MXL panel Models NIM 1W NIM 1M one 1 full Model MOM series card cage slot communicates directly with the MXL panel interface module NIM 1R Models NIM 1W NIM 1M function as a bridge each module is then takes no network addresses to the system configuration Hence the MXL function as one unified MXL X NET Communication Bridge 5069 Industry Inc Technologies Division Overview continued maximum of two 2 communication bridges can be in a series refer to Case Scenario 3 FireFinder Network Command Center a Global and or a global RCC Remote Command can serve as the central control monitoring The maximum amount of panel addresses MXL IQ MXLV and NCC allowed on a MXL system is 64 Interactive programming MXL panels is supported 4 or Style 7 wiring is supported among the MXL The modem transmission line connected Model NIM 1M is Style 4 Style 7 can be achieved using two sets of Models NIM 1M NIM 1W in both local and the remote panel NIM 1M is equipped with nine 9 status LEDs indicate the modem communication status and Humidity Range are UL 864 9th Edition listed for indoor locations within a temperature range of 49 2 to 32 3 0 2 and at a humidity of 93 2 at a temperature of 32 2 Documentation Sheet Number Data Ratings NIM 1W Voltage nominal 150mA NIM 1M analog modem Level Level Wire Loss rate Equipped with 2 wire RJ 11 and terminal blocks 2 wire leased line with auto Full duplex design FCC Part 68 registered FCC Part 15 compliant and Operation Manuals 315 099106 Local and Wide Area Interface Module 315 099105 modem daughter board designed for interconnection with Model NIM 1W Note For further details refer to MXL IOM manual 315 092036 for Ordering 315 699103 Local and Wide Area Interface Module 315 699104 modem daughter board designed for interconnection with Model NIM 1W Industry Inc Technologies Division Diagrams NIM 1M Dedicated Communication Specifications Lines Non powered no dial tone American Wire Gauge AWG Line condition e g noise signal loss rate should be tested Maximum signal loss tolerance is 25Dbm at 19.2K baud rate line conditioned for 19.2K baud modem communication rate Industry Inc Technologies Division Diagrams continued NIM 1W NIM 1M Application Scenarios This marketing data sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www SBT Siemens com FIS in U S A Safety Kenview Boulevard Ontario 5E4 Canada 905 799 9937 905 799 9858 2011 sheet dated 4 03 1
