Catalog XLS Control Module OCM 16 Provides 16 open collector outputs to drive incandescent lamps or external relays Contains output for local audible Provides two 2 inputs for module and Audible Silence All circuits are power limited Logic controls output activation Mounts remotely from control panel UL 864 9th Edition Listed ULC Listed CSFM NYMEA Approved Overview Output Control Module Model OCM 16 is a located general purpose output module provides 16 open collector outputs to drive LEDs lamps or external relays There is an output for a local audible and two inputs momentary lamp test as well as local audible switches OCM 16 is mounted in an enclosure that is located from the main control panel between Model OCM and Model is through the Control Area Network CAN Model OCM 16 has two 2 10 position rotary that are used to set the board address on CAN which is a sub address of Model NIC C 16 outputs of Model OCM 16 are controlled by received from the NIC C over the CAN bus Industry Inc Technologies Division View View CAN message can activate any or all of the 16 open outputs to drive LEDs incandescent 24 volt or relays any of the outputs are activated LEDs or relays are the local audible if installed will until acknowledged If the outputs are de before the alarm is acknowledged the alarm will lamp test and audible silence switch on multiple OCM 16 modules can be connected to a single one for each function A single audible can also used with multiple Model OCM 16 modules OCM 16 may be installed in a REMBOX2 REMBOX4 in any other UL 864 9th Edition approved enclosure using REMBOX2 or REMBOX4 mount Model OCM 16 in 1 space on the REMBOX2 MP or REMBOX4 MP Up four 4 Model OCM 16 modules will mount in Up to eight 8 Model OCM 16 modules will in REMBOX4 Model OCM 16 fits in a single module footprint XLS 6318 and Humidity Range are UL 864 9th Edition listed for indoor locations within a temperature range of 49 2 to 32 3 0 2 and at relative humidity of 93 2 at a temperature 90 3 32 2 for Ordering Ratings Back Plane Current Terminal 24V Current 14mA 10mA per Back Plane Current Standby Current 10mA per LED LED This marketing catalog sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www SBT Siemens com FIS in U S A Safety Kenview Boulevard Ontario 5E4 Canada 905 799 9937 905 799 9858 2010 sheet dated 7 09 2
