Siemens PAD-5 Addressable Power Supply Unit, Data Sheet

Accessories Addressable Power Supply Unit PAD5 6A PAD5 6A R PAD5 9A PAD5 9A R Engineer Specifications PAD 5 comes standard with a variable four 4 Class B two 2 Class A circuits and is expandable via Class B two 2 Class A circuits Power supplies support notification circuit NAC power up to 6A used with Model FP2011 U1 up to 9A used with Model FP2012 U1 Complete real time PAD 5 unit status the main fire alarm control panel 24VDC output voltage 3A of auxiliary output power Automatically recognized variable EOL values 2.2k 24k Multi module mounting in a two 2HU enclosure Model PAD 5 CLSA allows optional functionalities for pre action deluge clean agent Built in strobe synchronization supports coded audible signals Temporal 3 T4 patterns Form C general Trouble AC Fail contact Battery supervision and control Ground fault detection Advanced microprocessor control Uses Flash memory based system firmware optional system diagnostic firmware upgrade tool Americans with Disabilities Act compliant UL 864 10th Edition UL 1076 UL 2017 2572 Listed and ULC S576 14 Product Overview with Siemens Fire Safety fire alarm control panels FACPs PAD 5 is an UL 10th ULC S527 Listed addressable power supply unit that complies with the requirements of the Americans with Disabilities Act ADA Each PAD 5 can provide up to 9 Amps of NAC power with up to eight 8 supervised NACs auxiliary power output include Intelligent controller resides on SLC loop Four 4 Class A or eight 8 Class B NACs that can be mixed Class X wiring isolator device Temperature compensated battery charging circuits Trouble relays for remote monitoring Diagnostic light emitting diodes LEDs Alternating Current AC power connection Siemens NACs which connect with alarm signaling devices have been designed provide the highest level of reliability and performance coding on the circuits is accomplished through integrated circuits rather than which eliminates mechanical wear on the output circuits each PAD 5 unit supports P2 addressable communications and P2 fault indicators via use of a Model XDLC loop card connected to a Modular control panel Monitoring status and individual NAC control from single address are also provided by a PAD 5 unit Per ULC separate ground fault and indication for all remote power supplies are required The GND FLT provides a Normally Open N O Form A contact that can be monitored via a module such as Siemens Model HTRI series modules or the 4 In 4 Out Model FDCIO422 terms of electrical characteristics PAD 5 power supply units provide steady 24VDC voltage to each NAC independent of voltage fluctuations on the primary or power source Consequently a larger voltage drop and a greater wire for each NAC are supported by a Siemens PAD 5 unit Specifications Siemens PAD 5 can be configured in the following manner that makes the easily programmable Steady outputs Synchronized strobe outputs American National Standards Institute ANSI Temporal 3 ANSI Temporal 4 for carbon monoxide CO alarm signal March Time 30 60 or 120 PPM is also one 1 supervised NAC Follower input circuit that is driven by a FACP NAC or from a PAD 5 main board Model PAD 5 MB Infrastructure Building Products Sheet 3364 2 PAD 5 MB Boards One height unit 1HU two height unit 2HU are versatile housings size can be used any type of Siemens power supply and the Booster PAD 5 configuration of two 2 main boards in a two height unit 2HU enclosure Specifications continued 4 Class B or two 2 Class A NACs are standard 3A each for conventional reverse polarity 24 VDC notification appliances various operation modes four 4 outputs can be configured as non Alarm contact only input circuits Capability to mix and match Class A B expansion NAC circuits 6.5A or 9A power supply battery charger Charges internal batteries up to 18AH for 1HU up to 35AH for 2HU and up to in external cabinet Siemens Model BB 55 battery boxes available black or red status monitoring of battery input power Earth faults PAD 5 Unit Components main board Model PAD 5 MB used with PAD 5 notification extender units provides remote auxiliary for signaling appliances Model PAD 5 MB also allows for expansion of notification appliances NACs plug into each main board Each PAD 5 MB main board connects via the P2 loop of a Siemens X Loop Card Model XDLC connected to the Siemens Modular fire alarm control panel FACP Up to 32 PAD 5 main boards or mixture expansion cards can connect to one 1 Model XDLC at a time Model PAD 5 MB has one 1 address and is programmed with the Siemens Device Programmer Test Unit Model DPU in conjunction with PAD 5 units the Class A B Expansion Module Model PAD 5 CLSA provides connectivity of Siemens signaling appliances In order for proper additional functionality two 2 rated at 3A max are wired as Class A or four 4 circuits are wired as Class B Model PAD 5 CLSA one 1 address on the P2 loop The address for Model PAD 5 CLSA must be the next sequential address to that of the connected Model PAD 5 MB main board Model DPU programmer test unit is used to program the P2 address of each Model PAD 5 CLSA are LED indicators for each zone as well as for the P2 interface and for the status of the card Model PAD 5 CLSA can be used in Sinorix pre action deluge sprinkler or for clean agent There is an on board releasing disconnect switch that can be used to disable power to both releasing thus preventing accidental discharge of clean agent during routine maintenance 1HU enclosure PAD 5 Model PAD 5 MB PAD 5 CSLA to a Main Board Infrastructure Building Products PAD 5 Unit Components continued PAD 5 CDC is the Conventional Zone Module used with PAD 5 notification extender units each Model PAD 5 CDC supports four 4 Class A or four 4 Class B conventional zone input circuits The address for Model PAD 5 CDC must be the next sequential address to that of the connected Model PAD 5 MB main board to 30 Siemens conventional smoke detectors are supported per zone information per circuit is displayed from the Operating Unit of the Siemens Modular FACP Model PAD 5 CDC supports Siemens and other branded smoke detectors as well as one 1 detector per zone Additionally Model PAD 5 CDC provides optional alarm verification by as well as consistent ground fault detection PAD 5 CDC to a PAD 5 MB Board Enclosures There are two 2 types of unit enclosures for Siemens PAD 5 power units The one height unit 1HU Model PAB ENCL is the basic 1HU enclosure can hold one 1 170W one 1 300W Siemens power supply 1 PAD 5 main board and one 1 plate and one 1 Model PAD 5 CDC one 1 Model PAD 5 CLSA The two 2HU enc
