Siemens RL-30 RL-40 Remote Lamps, Installation Instructions

Installation Instructions RL 30 and RL 40 Lamps Models RL 30 round plate and RL 40 rectangular plate remote lamps from Siemens Industry Inc work a conventional detector The red lamp on the RL 30 or RL 40 lights when its associated detector goes into remote lamp may be placed up to 25 feet away from the detector using 18 gauge wire Use a single gang switch box user supplied for mounting the RL 40 Use a 4 inch octagonal conduit box supplied for mounting the RL 30 Make connections as shown in Figure 1 INDICATOR PER DETECTOR MAX INSTALLED CONTROL Do not use looped wire under terminal 5 wire run to provide supervision of connection 1 or RL 40 Connection Diagram RATINGS Voltage Industry Inc Technologies Park NJ 315 090672 1 Building Technologies Ltd Safety Security Products Kenview Boulevard Ontario 5E4 Canada
