Siemens RLC-11 RLW-11 Remote Lamps, Installation Instructions

Installation Instructions RLC 11 and RLW 11 Lamps Models RLC 11 round plate and RLW 11 rectangular plate remote lamps work with a PE 11 OP121 or HI121 detector The red LED on the RLC 11 or RLW 11 lights when its associated detector goes alarm remote lamp may be placed up to 25 feet away from the detector using 14 18 gauge wire Use a single gang switch box user supplied for mounting the RLW 11 Use a 4 inch octagonal conduit user supplied for mounting the RLC 11 Make connections to RL 11 as shown in Figure 1 a When connecting to the RR 11 Remote relay make the connections to relay base TB2 Refer to the Installation Instructions P N 315 094924 for further information When no connection to the RR 11 Remote relay is made route the wires through the hole in the base and make the connection to the screw terminals on the RL 11 as shown in Figure 1 or RLW 11 Connection Diagram 1 Industry Inc Technologies Division Park NJ 315 094925 6 Canada Ltd North Service Road East Ontario 0H6 Canada
