Siemens S3AP Adapter Kit for use with EN-PAD(R) or EN-RSE Enclosure or System 3 Rails, Installation Instructions

Installation Instructions S3AP Kit for use with EN PAD R or EN RSE Enclosure or System 3 Rails indoor use only in dry environments S3AP Adapter Kit from Siemens Industry Inc is in an EN PAD R or EN RSE enclosure or on 3 rails for use with a PAD 4 and FP2011 U1 Supply EN PAD EN RSE Enclosure Remove all system power before installation battery by removing the quick disconnects then AC Remove field wiring from terminal blocks of the PAD 3 or RSE 300 Remove the PAD 3 or RSE 300 by removing the 6 screws Place the screws to one side Place the S3AP adapter plate over the studs in the Using 4 of the 6 screws that were tighten the screws to the upper and left and right studs in the EN PAD R or enclosure as shown in Figure 1 Mount the FP2011 U1 Power Supply on the four at the top of the S3AP using the hardware with the FP2011 U1 as shown in Figure Refer to the FP2011 U1 installation instructions 315 050222 for further information Using the hardware from the PAD 4 place 4 in the bottom 4 studs of the S3AP Place PAD 4 over the screws and tighten them the remaining 2 screws in the upper right left corners of the PAD 4 as shown in Figure Refer to the PAD 4 Manual P N 315 050217 further information Refer to the EN PAD R Installation Instructions 315 099156 or the EN RSE Installation P N 315 099156FA for information on the door and the ground strap Industry Inc Technologies Division Park NJ 315 050257 0 1 the S3AP in an EN PAD R EN RSE Enclosure FP2011 U1 and PAD 4 on the S3AP 2 Canada Limited Technologies Division Kenview Boulevard Ontario L6T 5E4 Canada x 1 2 System 3 Rails Remove all system power before installation battery and then AC converting from a PAD 3 to PAD 4 the next to the PAD 3 will have to be to a different space Due to the size the S3AP plate the space adjacent to the on the System 3 rail will need to be left Place the S3AP adapter plate over the mounting in the desired location in the System 3 rails four 8 32 x 1 2 screws user supplied the S3AP to the System 3 rails on the and lower left and right slots of the adapter as shown in Figure 3 Note that the height of adapter plate can be adjusted to fit between rails Mount the FP2011 U1 Power Supply on the four at the top of the S3AP using the hardware with the FP2011 U1 as shown in Figure Refer to the FP2011 U1 installation instruc P N 315 050222 for further information Using the hardware from the PAD 4 place 4 in the bottom 4 studs of the S3AP Place PAD 4 over the screws and tighten them the remaining 2 screws in the upper right left corners of the PAD 4 as shown in Figure Refer to the PAD 4 Manual P N 315 050217 further information overall dimensions of the S3AP adapter plate 11 1 4 H x 1 16 D x 11 1 8 W 3 Rails 3 the S3AP on System 3 Rails
