Siemens SMBOX-XMP, APLT-XMP, 4DGBOX-XMP, Manual Pull Station, Installation Instructions

Pull Station Optional Accessories Instructions SMBOX XMP the Base as shown on Figure 1 using the 2 provided See the XMS S D M installation Document ID A6V11439600 for mounting and wiring the Pull Station APLT XMP the adapter plate with 3 screws supplied onto existing SB 5R surface mounting box the base onto the adapter plate using the 1 supplied and the 2 screws supplied with the Pull See the XMS S D M installation instructions ID A6V11439600 for mounting and wiring Pull Station 4DGBOX XMP adapter can be mounted either on the 4 inch box or the double gang electrical box the hardware provided mount the adapter on electrical box the XMS S D M installation instructions ID A6V11439600 for mounting and wiring Pull Station onto the adapter Model SMBOX XMP is a Surface Mounting Box P N 4W X 5.54H X 1.62 Deep Steel Painted color RAL 3020 Red Contents Surface Mounting Box Instructions Model APLT XMP is an adapter plate to mount the X Series Stations on the existing surface mounted boxes Model P N S54321 F21 A1 4W X 5 1 2H X 0.075 Thickness Steel Painted color RAL 3020 Red Contents Adapter Plate Instructions 100 Degrees Flat Phillips screws 6 32 x 3 8 long 6 32 long screw with External Tooth Lock Model 4DGBOX XMP is an adapter plate to be used to the X series Pull Stations on the 4 inch square box or a gang electrical box P N S54321 F22 A1 5W X 5.90H X 0.075 Thickness Steel Painted color RAL 3020 Red Contents Adapter Plate Instructions 100 Degrees Flat Phillips screws 6 32 x 3 8 long 100 Degrees Flat Phillips screws 8 32 x 3 8 long 1 the X Series pull stations onto the SMBOX XMP security disclaimer provides a portfolio of products solutions systems and services that security functions that support the secure operation of plants systems and networks In the field of Building Technologies this includes building and control fire safety security management as well as physical systems order to protect plants systems machines and networks against cyber threats it necessary to implement and continuously maintain a holistic state of the art concept Siemens portfolio only forms one element of such a concept are responsible for preventing unauthorized access to your plants systems and networks which should only be connected to an enterprise network the internet if and to the extent such a connection is necessary and only when security measures e g firewalls and or network segmentation are in Additionally Siemens guidance on appropriate security measures should be into account For additional information please contact your Siemens sales or visit https www siemens com global en home company topicareas portfolio undergoes continuous development to make it more secure strongly recommends that updates are applied as soon as they are and that the latest versions are used Use of versions that are no longer and failure to apply the latest updates may increase your exposure to threats Siemens strongly recommends to comply with security advisories on latest security threats patches and other related measures published among under https www siemens com cert en cert security advisories htm A5Q00073953
