Siemens SNU-series Single Node Upload modules for FireFinder panels, Data Sheet

s Sheet Safety Products XLS and XLSV Upload SNU Module SNU KIT SNU ASSY PS 5A and PMI 1 UPLD CBL AND ENGINEER SPECIFICATIONS Cost effective highly efficient processor designed for bidirectional data between the ZEUS tool FireFinder XLS V panels connected remotely Allows transferring and extracting of information in the Person Machine Interface PMI Up to 64 XLS XLSV panels can pass along system from as many SNU assemblies Utilizes a dedicated 128 bit secure Ethernet cable connection Universal Serial Bus USB cable is used between Model PMI 2 modules and each SNU assembly A serial cable Model PMI 1 UPLD CBL must be ordered for connection between a legacy Model PMI interface and each SNU processor One 1 Universal Serial Bus USB cable is included in each of the SNU assembly SNU hardware mounts in a separate enclosure ENCL 01 Each SNU assembly gets continuous power an integrated power supply Overview in conjunction with Siemens FireFinder XLS XLSV the Single Node Upload SNU is an optional module that provides a solution for uploading XLS XLSV configuration data remotely can easily transmit information from a personal running the ZEUS custom configuration tool to maximum 64 Person Machine Interfaces PMI dedicated Ethernet connection is the means used to SNU to directly provide information from the ZEUS to the remotely located PMIs Additionally the connection is separate from all existing system XNET HNET and DNET as well as any other devices USB connector used in regular ZEUS communication provides the physical connection between each PMI 2 and the SNU module for XLS fire or voice systems that operate with legacy Model PMI interface a serial cable Model PMI 1 must be ordered for use with the SNU assembly Details for Ordering on the following page mounting set up of a upload module UL 864 10th Edition and UL 1076 Listed 3rd Edition Listed CSFM and NYCFD Approved SNU module has three 3 connections Power and USB The data transported between ZEUS tool and SNU is made through a direct 128 Secure Sockets Layer SSL connection Data Ratings Alarm Current Standby Current Screw Terminal Current Back Plane Current Back Plane Current Properties W x H x D 13.3 2.75 cm 33.8 cm 7 cm 8 Lbs 3,629g Single Node Upload SNU Assembly 6360 Industry Inc Technologies Division Documentation XLS system overview XLSV system overview Machine Interface Power Supply Number for Ordering XLS Single Node Upload SNU kit One 1 ENCL 01 enclosure with key lock door One 1 PS 5A power supply mounting screws included One 1 SNU ASSY processor One 1 Universal Serial Bus USB cable connection between a SNU module and Model PMI 2 One 1 processor cable connection between a SNU assembly and the 24VDC power supply Model PS 5A One 1 SNU Installation Operations Manual IOM A6V10525432 enclosure with key lock 5V Power Supply Module UPLD CBL S54430 A4 A1 Adapter Cable for USB to serial converter connection between single node upload assemblies and 1st Person Machine Interfaces This marketing data sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Technologies Division Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www USA Siemens com FIRE Safety North Service Road Oakville Ontario 0H6 Canada 905 465 8000 www Siemens CA in U S A 2016 sheet dated 4 2016 1
