Siemens ST Series Strobes and Strobe Plates Indoor Outdoor, Data Sheet

s Sheet Safety Products Appliances Strobes and Strobe Plates Applications Indoor Outdoor Plate Overview ST HMC CW Strobe Strobes feature low current draw Ceiling mount multi Candela models are available with field selectable settings of 15 30 75 95cd or 115 177cd Wall mount multi Candela models are available with field selectable settings of 15 30 75 110cd Strobes produce one 1 flash per second over the regulated voltage range Synchronized using the Siemens DSC sync modules the Siemens 50 point 252 point 504 point fire alarm control panels FACPs as well as with XLS and MXL FACPs or PAD 4 NAC Extenders with built in sync protocol Fast installation with In Out screw terminals using 12 to 18 AWG wire Listed ULC Listed and CSFM Approved 7125 0067 0252 Fire Alarm Devices For The Hearing Impaired non weatherproof 7125 0067 0256 Fire Alarm Devices For The Hearing Impaired weatherproof Meets OSHA 29 Part 1910.165 Visual notification appliances are Siemens Series ST Strobe Appliances or approved equals The Series ST meet and are listed for UL Standard 1971 for Indoor Fire Protection Service Devices for the Hearing Impaired Strobes are listed for indoor use only Strobe appliances produce a flash rate of one 1 flash per second over the Regulated Range and incorporate a Xenon flashtube enclosed in a rugged Lexan lens All inputs are compatible with standard reverse polarity supervision of circuit wiring a Fire Alarm Control Panel FACP Strobe Plates when installed are the Siemens Series Strobe Plate ST MC RETRO will have the same electronic circuitry as the Siemens Series ST The Series ST Strobe are of low current design The selector switch for selecting the candela is tamper resistant Series Strobes and Strobe Plates 2573 Industry Inc Technologies Division continued The strobe intensity for ceiling mount models has field selectable settings and is rated UL Standard 1971 for 15 30 75 95cd or 115 177cd where multi Candela appliances are specified The strobe intensity for wall mount models has field selectable settings and is rated per Standard 1971 for 15 30 75 110cd where multi Candela appliances are specified When synchronization is required the appliance is compatible with Siemens DSC Sync Modules Siemens 50 point 252 point and 504 point fire alarm control panels FACPs as well as with FireFinder XLS and MXL FACPs PAD 3 or PAD 4 NAC Extenders with built in sync protocol The strobes will not drift out of synchronization at any time during operation If the sync module or Power Supply fails to operate i e contacts remain closed strobe will revert to a non synchronized flash rate The strobes are designed for indoor surface of flush mounting All notification appliances are backward compatible The Series ST Strobe Appliances incorporates a patented strobe mounting plate allows mounting to any of the following one 1 single gang or double gang 4 inch square 10.2 cm back box one 1 Model SHBBS surface back box one 1 Model SBL2S surface back box used only with Model ST MC RETRO R Notes Strobes are designed to flash at one 1 flash per second minimum over their Voltage Range All candela ratings represent minimum effective Strobe intensity based on 1638 and UL Standard 1971 All notification appliances are listed for Applications NFPA 72 specifies a flash rate of 1 to 2 flashes per second ADA Guidelines specify a flash rate of 1 to 3 flashes per second Diagram Shown In Inches Options Industry Inc Technologies Division Data Series Strobe Wall Mount Ratings AMPs Voltage 16.0 33.0VDC 16.0 33.0VRMS 0.108 RMS Current ST HMC CW Series Ceiling Mount Ratings AMPs Voltage RMS Current 30cd 75cd 95cd 115cd 177cd 16.0 33.0VDC 0.069 0.111 0.200 0.264 0.318 0.445 16.0 33.0VRMS 0.117 0.180 0.297 0.398 0.482 0.684 Strobe Wall Mount Weatherproof Ratings AMPs Strobe Ceiling Mount Weatherproof Ratings AMPs Voltage UL1638 RMS Current 180cd UL 1971 Voltage UL1638 RMS Current 180cd UL 1971 16.0 33.0VDC 16.0 33.0VRMS 33.0VDC 33.0VRMS Strobe Wall Mount Weatherproof Ratings AMPs Strobe Ceiling Mt Weatherproof Ratings AMPs Voltage 16.0 33.0VDC 16.0 33.0VRMS RMS Current Voltage 16.0 33.0VDC 16.0 33.0VRMS RMS Current Series Strobes Weatherproof UL ULC Models and Ratings Voltage Application UL 1638 UL1971 and UL464 VDC VRMS Range CAN ULC S526 02 40 UL1638 Rated Strobe Candela cd 33.0 33.0 33.0 33.0 Available in red or white 31.0 75 90 1 Strobe will produce 1 flash per second over the Input Voltage range This strobe horn model meets the required light distribution patterns defined in 1638 UL 1971 ULC S526 02 This model is UL Listed for indoor use with a temperature range of 32 to 120 to 49 1638 is tested from a temperature range of 40 to 150 40 to 66 a maximum humidity of 95 RH 180 180 177 185 is on Axis only Rated Output effect of shipping and storage temperatures will not adversely affect the performance of the appliance it is stored in the original cartons and is not subjected to either misuse or improper handling of shipment Industry Inc Technologies Division for Ordering Including Mounting Options Agency Approvals Agency Approvals CSFM Strobe Candela Ceiling White Strobe Hi Multi Candela Ceiling White Strobe Multi Candela Red Strobe Multi Candela White Strobe Multi Candela Retro Plate Red Strobe Weatherproof Ceiling Red Strobe Weatherproof Ceiling White Strobe Weatherproof Wall Red Strobe Weatherproof Wall White Hi Multi Candela Ceiling Red Hi Multi Candela Ceiling White Hi Multi Candela Wall Red Hi Multi Candela Wall White 1 Strobe Agent Release Only AGENT text Red Refer to Sinorix Fire Suppression data sheet 6634 for more information For Model ST AMC amber and ST CMC clear strobe appliances are used exclusively for mass notification refer to data sheet 2588 Siemens WPS KIT is comprised of one 1 hardware package two 2 red plugs two 2 white p
