Siemens TSM-1 Test Switch Module, Installation Instructions

Fire Safety LIMITED WIRING FOR THE TSM 1 SWITCH MODULE compliance with NFPA 70 Electrical all power limited fire protective signaling must be separated by a minimum of from all of the following items located within an box Electric light Power Class 1 or non power limited fire protective conductors Remove the module from its protective bag the TSM 1 in a user supplied standard gang mounting box 1 in deep is Refer to Figure 1 Terminate all field wires to the TSM 1 as required your application Refer to the connection shown in Figures 2 and 3 Attach the switch frame to the box Check that jumper JP1 is NOT installed JP1 is used in this application Attach the keyswitch connector to its mating plug the bottom of the circuit board the face plate and attach the cover plate the two screws provided A yellow and green LED are included in the Do not use them in this application Building Technologies Ltd Derry Road West Ontario L5N 7A6 Canada Instructions TSM 1 Switch Module Model TSM 1 Test Switch Module from Siemens Technoliges Inc is a key activated momen switch for use with intelligent duct detectors on MXL System It is used in conjunction with a TRI CSG M usage is set to TEST When the TRI the TSM 1 switch closure it will cause its intelligent duct detector to go into alarm alarm condition will cause all logic associated the duct detector to activate The TSM 1 is on a switch plate and can be installed in a gang box all power from the system until the is complete and ready for testing work of any kind shall be performed to meet requirements of all local and national codes standards required by the authority hav jurisdiction INSTRUCTIONS to the wiring diagrams in Figures 2 and 3 wire the addressable interface module to the appropriate operation for your The recommended wire size is as follows AWG minimum AWG maximum Building Technologies Inc Fernwood Road Park New Jersey 07932 315 098285 8 Use the FPI 32 Programmer Tester to program TRI to the desired address Select STATUS the usage To operate the TSM 1 LED by the TRI R relay the CSG M configure the TRI by setting its to TEST and assign the detector to the TRI R Add a logic function with intelligent detector that will be tested as the and assign the output as the TRI R Refer Figure 2 To operate the TSM 1 LED by the air duct the CSG M configure the TRI by setting its to TEST Add a logic function with the detector that will be tested as the and assign the output as the fan shutdown operated by the air duct detector Refer to 3 the MXL System until SYSTEM NORMAL is on the panel Insert the key into the keyswitch input point on the TSM 1 Activate momentary switch by turning the key to the right the TSM 1 keyswitch is activated the super switch input of the TRI R is closed The TRI R is received by the MXL panel The MXL then sends a reduced alarm threshold to the through the TEST usage of the TRI R This the detector to alarm the detector goes into alarm and sends alarm back to the MXL panel the MXL panel sends data to the TRI R or air duct to close the which activates the fan controller through the function The MXL panel sends a signal to the detector turning on the red LED in both the and the TSM 1 indicating the detector is in the system The MXL System will restore the alarm threshold and display SYSTEM on the panel CAUTION TSM 1 switch does not perform all of the required smoke detector tests as speci in NFPA Standard 72 Please refer to the instructions that accompany the smoke for the complete test requirements 1 Assembly MXL Loop of Line Device TRI R 1 4W 140 820185 contact rating 10mA min Air Duct or next on loop VDC 20mA max MMB 2 TB5 MMB 3 TB9 9 12 PSR 1 TB3 3 6 UL Listed Supply For use only with Air Ducts with an incorporated relay Refer to the TRI Installation Instructions P N 315 096242 for specific interface module wiring requirements Refer to the AD 11PR AD 11XPR Installation Instructions P N 315 095659 or the AD 3I 3ILP Installation Instructions 315 093234 for specific duct detector wiring requirements as applicable 2 Interface to MXL System LED operated by the TRI R relay contacts MXL Loop of Line Device TRI R 1 4W 140 820185 contact rating 10mA min Air Duct Detector next device on loop Fan Air Duct Detector Detector Installation for Remote Indicator For use only with Air Ducts without an incorporated relay Refer to the TRI Installation Instructions P N 315 096242 for specific interface module wiring requirements Refer to the AD 11P Installation Instructions P N 315 095659 or the AD 3I 3ILP Installation Instructions P N 315 specific duct detector wiring requirements as applicable 3 Interface to MXL System LED operated by the Air Duct Detector Building Technologies Inc Fernwood Road Park New Jersey 07932 315 098285 8 Building Technologies Ltd Derry Road West Ontario L5N 7A6 Canada
