Siemens TSM-1X Intelligent Test Switch and Status Indicator, Data Sheet

and Detection Devices Device Test Switch and Status Indicator TSM 1X Architect Engineer Specifications Intelligent test switch module with normally open N O activated T45 switch Dual built in isolators Meets Class X Style 7 requirements Multi color light emitting diode indicates system status GREEN AMBER RED Low current draw Restriction of Hazardous RoHS compliant Mounts in a single gang box 3.5 inches 8.9 cm deep Device Programmer Tester DPU programs and device address programming capabilities include a duct detector as well as Siemens addressable devices Capability of being installed on a communication loop on the wiring of that loop UL864 UL2572 UL2017 Listed CAN ULC S576 Listed File S24304 Vol 3 Product Overview Siemens Fire Safety Intelligent Test Switch Module Model TSM 1X is a key T 45 addressable normally open N O momentary switch with a tri light emitting diode LED indicator The tri color LED mimics the status of the Siemens smoke detector or compatible device s Each Model TSM 1X can be configured to test and monitor group of devices using one 1 address the fire alarm control panel FACP loop TSM 1X provides a valid test of a Siemens duct detector even the detectors in inconspicuous inaccessible areas and will test associated logic functions duct housings and other modules Other common applications include fan switch drill switch recall switch and remote Arm Disarm switch Refer to installation manual P N A6V101055486 to ensure Model TSM 1X with the Siemens FACPs intended for use in the given application Model TSM 1X is an economical solution since each X series Test Switch provides combined pre packaged functionality of Siemens In Out TRI S Siemens status indicators ILED series and T 45 test switches there is no longer the need of having to buy individual parts and them in the field Additionally Model TSM 1X is modernized through its to provide built in isolation which shows the location of a short Specifications TSM 1X is designed for use with addressable duct detectors or other intelligent on a Device Loop Circuit DLC of Siemens compatible Fire Alarm Control FACP Turn key activation will cause all associated logic functions to be Typical applications in which key activation is used include intelligent duct hidden or inaccessible smoke detectors Fan Recall Restart Drill and Arm Disarm switches This alarm condition will cause all logic associated with duct detector to activate The TSM 1X is mounted in a 3.5 inch 8.9 cm deep back box which is supplied by others BO mode TSM 1X supports two 2 operation methods Polarity insensitive mode module can be wired in either mode and configured by the Siemens FACP While in isolation the built in dual will work at both sides of the module to isolate a line in front or behind the module TSM 1X provides intelligent built in dual Class X Style 7 survivability requirements for shorts providing reliable alarm communication to the Siemens Additionally Model TSM 1X allows up to 190 isolators per and up to 30 devices between isolators wired in polarity mode The devices between isolators can either be H or later X generation devices Technologies Division Data Sheet 6198 usa siemens com fire TSM 1X Detector Test Switch TSM 1X faceplate Single gang switchbox supplied The single gang electrical box seen in this depiction is supplied by others BO Specifications continued isolation feature found on a Model TSM 1X Test Switch provides a location of the fault short When a short occurs Siemens FACP can identify the fault automatically and the module recognized the short location in front of the or behind the device Overall the built in isolators improve the diagnostics and location of the short and report a Class X module is misconfigured Test Switch Module is configurable by a Siemens compatible panel s in an isolator polarity sensitive or non isolator insensitive mode When Model TSM 1X is configured as an isolator it may serve a dual purpose by simultaneously as a test switch and status indicator and isolator Advanced troubleshooting is provided by compatible Siemens via identification for when a Model TSM 1X Test Switch is configured as an isolator but is wired incorrectly in a insensitive mode Operation Programmer Test Unit Test Switch is programmed with the Siemens field device programmer test unit Model DPU which is a compact and menu driven accessory for electronically programming and testing Siemens peripheral modules and devices and reliably For instance the field technician selects the accessory program mode and enters the desired Vibration corrosion and other conditions that deteriorate mechanical addressing mechanisms are no longer a for concern Each remote alarm lamp is connected to Model DPU with the programming cable provided with the This programming cable P N 110 694927 utilizes two 2 clip connectors to attach to the module Since Model TSM 1X Test Switches are advanced initiating devices the latest Model DPU firmware update is required set in test mode Model DPU will perform a series of diagnostic tests without altering the address or other stored allowing technicians to determine if the detector is operating properly field device programmer test unit operates on AC power or rechargeable batteries providing flexibility and in the programming testing of fire safety equipment from practically any location Additionally with the of a Model DPU unit there is no longer a concern with any vibration corrosion and other deteriorating conditions compromises the vitality of a mechanical addressing mechanism Model DPU electronically sets the interface for each Model TSM 1X into the non volatile memory of the interface microcomputer chip Model TSM 1X module is fitted with screw terminals for connection an addressable circuit with compatible Siemens FACPs Refer to installation manual P N A6V101055486 to ensure Model TSM 1X with the Siemens FACPs intended for use in the given application Data Model TSM 1X from Siemens is an intelligent key activated device that tests detectors for associated logic functions for functionality A Model TSM 1X Test Switch operates with any Siemens intelligent fire smoke and duct detector used a compatible Siemens FACP Other applications include the testing of logic functions of inconspicuous inaccessible detectors Fan Recall Restart Drill and remote Arm Disarm switches the TSM 1X momentary switch is activated a signal is transmitted to the Siemens compatible FACP resulting in the detector on the configuration network to go into Alarm mode In turn the Alarm event will activate all programmed to follow the detector For this reason Model TSM 1X provides a valid accurate test of Siemens detectors used on Siemens FACPs therefore meeting the requirement found in local fire safety jurisdictions Model TSM 1X Test Switch mounts in a single gang electrical back box each shipment includes a cover plate Technologies Division Compatibilities X modules may be used along with Model H intelligent detectors Model HMS addressable stations or any other H addressable intelligent module e g Model HZM or Model HCP Siemens X and H detection devices on the same loop is mostly permitted but there exceptions Models HLIM isolation module and SBGA 34 audible base cannot be used with X on the same loop Temperature and Humidity Range Detector Test Switches are UL Listed ULC Listed Environmental operating conditions for each Model TSM 1X is 32 0 to 120 49 w
