Siemens VNT-MP Mounting Plate, Installation Instructions

Installation Instructions VNT MP Plate for the VNT Model VNT MP Mounting Plate from Siemens Building Technologies Inc is for in CAB1 CAB2 and CAB3 enclosures for mounting the VNT VNT PS Ethernet Fiber Switch module and XND modules One VNT MP can be installed in a CAB2 or CAB3 enclosure Mounting Plate is for indoor use only in dry environments all system power before installation first battery then AC To power up the AC first then the battery VNT MP mounts in the bottom row of a CAB1 CAB2 or CAB3 enclosure using four 10 32 screws provided the four screws in the CAB1 CAB2 or CAB3 backbox in the positions by the the numbers and in Figure 1 Place the four holes the VNT MP Mounting Plate over the screws Refer to Figure 2 the four screws to secure the mounting plate in place 1 Mounting Positions 315 050489 0 Building Technologies Safety WITH SCREWS 4 PLACES 2 VNT MP Mounting Plate in CAB2 Enclosure Jumpers the two jumpers P N 110 398369 included with the VNT on the terminal block the VNT MP as shown in Figure 3 JUMPERS ON BLOCK SHOWN 3 Jumpers on VNT MP Terminal Block VNT MP can be used in CAB1 CAB2 and CAB3 enclosures Mounting Plate 14.25 x 14.25 Building Technologies Inc Fernwood Road Park New Jersey 07932 Building Technologies Ltd Derry Road West Ontario L5N 7A6 Canada 315 050489 0
