The Model XDACT ASSY is an optional assembly that can be mounted on the inner doors next to a or a PMI 3 or in the second row of inner doors of CAB2 and CAB3 INSTRUCTIONS XDACT ASSY Supplied Dialer bracket q 1 Locknuts q 2 Cable harness q 1 2 pos connector plug q 1 sheet REQ REAR DOOR FCA2015 U1 1 Mounting the Dialer Siemens Industry Inc Building Technologies Division AWG AWG 2 2 2 Power Connection to Dialer first then the battery Remove all system power before installation first battery then AC To power up connect the Mount the dialer bracket in either row 1 or row 2 of the inner door using the two locknuts Mount the dialer Model FCA2015 U1 P N S54400 A63 A1 on the bracket using the four provided with the Dialer Remove the plastic rear cover of the PMI by removing only the four screws Connect the cable harness provided to the PMI connector header and to the Dialer Plug the 2 pos connector provided into the dialer as shown in Figure 2 Use two 12 22 AWG to connect it to the power supply Connect the black wire from connector TB3 to the connector on the dialer X102 2 See Figure 2 Reinstall the PMI rear cover that was removed in Step 4 Refer to the FCA2015 U1 DACT Installation Instructions Document ID A6V10334254 for more including telephone connection wiring Apply power to the system Configure using Zeus programming tool See the Zeus Quick Start Manual P N 315 033875 for details on programming Check for proper operation security disclaimer products and solutions provide security functions to ensure the secure operation of building comfort safety security management and physical security systems The security functions on these products and are important components of a comprehensive security concept is however necessary to implement and maintain a comprehensive state of the art security concept that customized to individual security needs Such a security concept may result in additional site specific action to ensure that the building comfort fire safety security management or physical security for your site are operated in a secure manner These measures may include but are not limited to networks physically protecting system components user awareness programs defense in depth additional information on building technology security and our offerings contact your Siemens sales or department We strongly recommend customers to follow our security advisories which provide on the latest security threats patches and other mitigation measures http www siemens com cert en cert security advisories htm ID A6V10807278 enUS b A5Q00069411
