Siemens ZAC-40 Desigo Modular Zone-Amplifier Card, Data Sheet

Fire Safety system Card 40 Watt ZAC 40 Engineer Specifications 40 Watt plug in audio amplifier Selectable audio levels 40 Watts 40 Watts Local audio input Speaker lines supervised active or inactive Style Y or Z wiring Split zone A B wiring on Style Y Plugs into either a Model CC 5 or CC 2 Card Cage Supports and switches up to eight digital audio channels Internal amplifier supervision Back up amplification available UL864 CAN ULC S576 Listed CSFM NYC Fire Department Product Overview Zone Amplifier Card Model ZAC 40 is a combination 40 Watt amplifier zone for use with Desigo Fire Safety Modular panels Style Y Z or B wiring configurations are supported Model ZAC 40 is power limited can be configured to provide 40 Watts of audio at 25VRMS or 70VRMS ZAC 40 is a plug in card that mounts in a Model CC 5 or CC 2 card cage ZAC 40 is capable of amplifying any of the 8 eight digital audio channels are transmitted from the Digital Audio Card Model DAC NET via the digital bus Audio Serial Interface Model ASI Model ZAC 40 amplifier is supervised functionality ZAC 40 can be used as a single 40 Watt speaker zone 1 one to eight 8 channel applications or as a bulk for one or two channel applications feeding high audio to Models ZIC 4A and ZIC 8B or for single channel feeding high level audio to Model HCP Model can also send audio to additional speaker zones via use of the Model EBA2004 A1 booster amplifier speaker lines are supervised for open short circuit and fault The speaker lines are also supervised in both active and inactive states provide amplifier backup additional Model ZAC 40 cards be used to achieve the desired amplifier backup ratio of 1 1 or 1 to many ZAC 40 takes one 1 sub module address of Model and receives control and communication data from DAC NET via the CAN bus on Model DAC NET ZAC 40 contains an inherent Mode backup Slow Whoop that serves as a secondary backup to the backup tone or digital message provided by Model Amplifier Card ZAC 40 Infrastructure Building Products Data Sheet 7331 Overview continued local audio input is provided to connect an external audio source The local audio input is activated via an external and has the lowest priority of all signals Model ZAC 40 is FM 3015946 3026902 CSFM 6812 0067 237 FDNY 6160 Approved the Zone Amplifier Card meets the UL 464 requirement for 520 Hz low frequency signal tone as described the section for Determination of Low Frequency Signal Format in the Standard for Audible Signal Appliances when used with Models and series of Siemens high fidelity notification appliances Compatibilities OR TYPE SHEET Notification Appliances Series Notification Appliances Series Fire Safety Booster for Ordering NUMBER Amplifier Applications Fire Evacuation Convenience Paging Tornado Alert Terror Alert Building Emergency Background Music and Humidity Range ZAC 40 is UL864 9th Edition Listed for indoor locations within a temperature range of 120 3 to 32 3 0 2 and a relative humidity 93 2 at a temperature of 90 3 32 2 Ratings POWER CURRENT DRAW Plane CURRENT Terminal 40W 20W 10W 0W CURRENT DRAW Plane CURRENT DRAW CONTACT INPUT 10mA power limited NOTICE The information contained in this data sheet document is intended only a summary and is subject to change without notice product s described here has have a specific instruction sheet s cover various technical limitation and liability information of install type instruction sheets as well as the General Product and Limitations document which also contains important data provided with the product and are available from the Manufacturer contained in the aforesaid type of documentation should be consulted a fire safety professional before specifying or using the product further questions or assistance concerning problems that might arise relative to the functioning of the equipment please contact Manufacturer Fire Safety Industry Inc Infrastructure Building Products Fernwood Road Florham Park NJ 07932 973 593 2600 2019 1
