Siemens ZAM-180 Zone-Amplifier Module (180-Watt), Data Sheet

Data Sheet Safety Products AND ENGINEER SPECIFICATIONS XLS Module 180 Watt ZAM 180 180 Watt audio amplifier Selectable audio levels 25VRMS 150 Watts 70VRMS 180 Watts Local audio input Speaker lines supervised when active or inactive Style Y or Z wirings Split zone A B wiring on Style Y Takes one 1 module space mounting directly on box or optional Model CAB MP mounting plate Supports and switches up to eight 8 digital audio channels Internal amplifier supervision Backup amplification available UL 864 9th Edition Listed and ULC Listed CSFM NYC Fire Department Approved Overview ZAM 180 is a combination 180 watt amplifier zone for use with FireFinder XLS Style or wiring is supported as well as split zone B speaker zone wiring configurations on Style ZAM 180 can be configured to provide 150 watts audio at 25VRMS or180 watts of audio at 70VRMS ZAM 180 takes one 1 module space and mounts on back box or optional Model CAB MP mounting Model ZAM 180 is capable of amplifying any of the 8 digital audio channels that are transmitted from DAC NET via the digital audio bus audio serial Model ASI ZAM 180 is supervised for functionality one to eight ZAM 180 can be used as a single 180 Watt zone channel or as a bulk amplifier for 1 one or two 2 applications feeding high level audio to Model or Model ZIC 8B The speaker lines are supervised open short circuit and ground fault applications and supervised in both the active and inactive states Industry Inc Infrastructure Building Products provide amplifier backup additional Model ZAM 180 can be used to achieve the desired amplifier ratio of 1 to 1 or 1 to many ZAM 180 takes one 1 sub address of Model DAC and receives control and communication data from DAC NET via the CAN Bus on the DAC NET ZAM 180 contains an inherent degrade mode tone Slow Whoop which serves as a secondary to the primary backup tone or digital message by Model DAC NET Additionally local audio is provided to connect an external audio source The audio input is activated via an external contact The input has the lowest priority of all signals Note ZAM 180 meets the UL464 requirement for 520 low frequency signal tone as described in the section Determination of Low Frequency Signal Format in the for Audible Signal Appliances when used with and series of Siemens high fidelity appliances Zone Amplifier Module 6332 Applications Fire Evacuation Tornado Alert Terror Alert Building Emergency Convenience Paging Background Music and Humidity Range ZAM 180 is UL 864 9th Edition Listed for indoor locations within a temperature range of 120 3 2 to 32 3 0 2 and a relative of 93 2 at a temperature of 3 32 2 Ratings Power Back Plane Current Current Terminal 190W 90W 45W 0W Back Plane Dry Contact Current Standby Output Power 190W 90W 45W Back Plane Current 10A power limited for Ordering 500 035600 180 Watt Zone Amp This marketing data sheet is not intended to be used for system design or installation purposes the most up to date information refer to each product installation instructions Industry Inc Infrastructure Building Safety Fernwood Road Park NJ 07932 973 593 2600 908 547 6877 www usa Siemens com Fire in U S A Safety North Service Road Oakville Ontario 0H6 Canada 905 465 8000 www Siemens CA 2019 4
