Sheet Safety Products Appliances ZR Strobes Horns Horn Strobes Indoor ZH mounting Overview can be synchronized using the Siemens DSC sync modules the Siemens 50 point and 504 point addressable fire alarm control panels FACPs as well as with FireFinder XLS and MXL FACPs PAD 3 or PAD 4 NAC Extenders with built in sync protocol Continuous Horn or Temporal Code 3 Tones with 90 or 95 dBA setting Series models feature field selectable Candela settings of 15 30 75 95cd and 115 177cd Wall mount models feature field selectable Candela settings of 15 30 75 110cd and 135 185cd plate is protected by a disposable cover and the appliances can quickly snap onto the base the walls are painted produce one 1 flash per second Applications listed with Siemens panels Mount Universal Mounting Plate Model ZB Series uses single plate ceiling and wall mount installations Mount design with separate base plate provides ability to pre wire the base test the circuit wiring before the walls are covered Listed ULC Listed FM 3028994 Approved Approved Series 7125 0067 0248 Fire Alarm Devices For The Hearing Impaired Approved Series 7125 0067 0252 Fire Alarm Devices For The Hearing Impaired ADA NFPA compliant General Audible Visual notification appliances are listed for indoor use only Appliances are listed under UL Standard 1971 Standard for Safety Signaling Devices Hearing Impaired and UL Standard 464 Fire Protective Signaling Appliances use a universal back plate which allows mounting to a double gang 4 inch square 10.2 cm 4 10.2 cm or a 3 1 2 8.9 cm octal backbox configurations allows capability for directly connecting appliances to the mounting back plate Continuity check will occur for entire NAC circuit prior to attaching any audible visual notification appliances A cover fits over the mounting plate for protection to dust and other outside elements Cover is easily removed when the appliance is installed over the back plate of an appliance will result in a Trouble condition by the Siemens Fire Alarm Control Panel FACP Series Notification Appliances 2584 Industry Inc Technologies Division continued and Audible Strobe Combinations appliances produce a minimum flash rate of 60 flashes per minute 1 flash per second over the Regulated Input Voltage Range and a Xenon flashtube enclosed in a rugged Lexan lens are available with two 2 or four 4 field selectable settings one 1 unit and are rated per UL 1971 for up to 15 30 75 110cd for wall mounted 135 185cd for wall mounted 15 30 75 95cd for ceiling mounted 115 177cd for ceiling mounted operate over an extended temperature range of 32 to 120 to 49 and be listed for maximum humidity of 95 RH inputs are polarized for compatibility with standard reverse polarity of circuit wiring by a Siemens FACP Audible and Audible Strobe Combinations Horns and horn strobes are listed for Indoor use under UL Standard 464 Horns are able to produce continuous synchronized output or a Code 3 synchronized output Horns have at least two 2 sound level settings of 90 and 95 dBA Modules strobe portion when synchronization is required is compatible with the DSC sync modules the Siemens 50 point 252 point and 504 point FACPs as well as with FireFinder XLS and MXL FACPs PAD 3 or PAD 4 NAC Extenders with built in sync protocol strobes will not drift out of synchronization at any time during operation and strobes are able to synchronize on a two wire circuit with the capability silence the audible if required revert to a non synchronized flash rate if the sync module or supply should fail to operate i e contacts remain closed All notification appliances are listed for Special Applications Strobes are designed to flash at 1 flash per second over their Regulated Input Voltage Range Note NFPA 72 specifies a flash rate of 1 to 2 flashes per second ADA Guidelines specify a flash rate of 1 to 3 flashes per second All candela ratings represent minimum effective Strobe intensity based on UL Standard 1971 Series ZH Strobe products are listed under UL Standards 1971 and 464 for indoor use a temperature range of 32 to 120 0 to 49 and maximum humidity of 93 2 Series ZH horns are listed under UL Standard 464 for audible signal appliances Indoor use only Diagram Industry Inc Technologies Division In Inches Diagram Data Horn Wall and Ceiling Mount Voltage Special Application Voltage 33.0VDC 16.0 33.0VRMS Current draw is the same for the Continuous Horn Code 3 and March Time settings UL 464 Horn Strobe Series Wall Mount Ratings AMPs Voltage RMS Current with High dBA Setting 30cd 75cd 110cd 135cd 185cd 16.0 33.0VDC 0.078 0.113 0.195 0.259 0.371 0.506 16.0 33.0VRMS 0.141 0.200 0.302 0.406 0.521 0.722 Ratings AMPs Voltage RMS Current with Low dBA Setting 30cd 75cd 95cd 135cd 185cd 16.0 33.0VDC 0.070 0.107 0.188 0.246 0.324 0.455 16.0 33.0VRMS 0.123 0.179 0.290 0.391 0.497 0.699 Strobe Series Wall Mount Ratings AMPs Voltage Setting cd 30cd 75cd 110cd 135cd 185cd 16.0 33.0VDC 0.064 0.098 0.175 0.233 0.318 0.445 16.0 33.0VRMS 0.108 0.164 0.268 0.368 0.482 0.684 Strobe Series Ceiling Mount Ratings AMPs Voltage Setting cd 30cd 75cd 95cd 115cd 177cd 16.0 33.0VDC 0.069 0.111 0.200 0.264 0.318 0.445 16.0 33.0VRMS 0.117 0.180 0.297 0.398 0.482 0.684 Directional Characteristics dBA dBA degrees left 40 degrees right degrees left 65 degrees right Industry Inc Technologies Division Horn Strobe Series Ceiling Mount Ratings AMPs Voltage RMS Current with High dBA Setting 30cd 75cd 95cd 115cd 177cd 16.0 33.0VDC 0.087 0.131 0.222 0.292 0.371 0.506 16.0 33.0VRMS 0.149 0.216 0.331 0.436 0.521 0.722 Ratings AMPs Voltage RMS Current with Low dBA Setting 30cd 75cd 95cd 115cd 177cd 16.0 33.0VDC 0.075 0.121 0.213 0.277 0.324 0.455 16.0 33.0VRMS 0.131 0.195 0.319 0.421 0.497 0.699 and ZH MC Series Wall and Ceiling Mount Per UL 464 VDC 24.0 VDC 33.0 VDC Sound Output 3 Horn March Time Sound Output 3 Horn March Time Available only in sync mode Per ULC S525 99 VDC 24.0 VDC 31.0 VDC Data continued Strobes will produce 1 flash per second over the Input Voltage range These horn strobe models are UL Listed to operate over a Voltage Range Limit from 16.0VDC to 33.0VDC 24VDC applications using filtered DC or unfiltered Full Wave Rectified FWR input voltage All models are UL Listed for indoor ceiling use with a temperature range of 0oC to 49oC to 120oF and maximum humidity of 93 2 RH effect of shipping
