Siemens ZIC-4A Desigo Fire Safety Modular Zone Indication Card, Data Sheet

Fire Safety system Card Model ZIC 4A Architect Engineer Specifications Operates audible or visual appliances One 1 or 2 two channel operation Operates audio speakers or 70VRMS Three 3 unique signals each circuit Available bell follower application Four 4 Class A or Class B circuits 24 VDC at 3.0 Amps per circuit Built in strobe synchronization City tie or leased line output Coded audibles available Fully programmable On board microprocessor Automatic manual control March time Uniform Code 3 Selectable degrade operation Built in ground fault detection Silenceable non silenceable option Circuits power limited per NEC 760 NFPA 13 pre action and deluge NFPA 2001 FM 200 Releasing Releasing service FM Approved for single and interlock pre action 0peration UL 864 9th Edition Listed ULC FM 3010 NYC 6160 Dept Approved Technologies Division Product Overview Zone Indicating Card Model ZIC 4A provides four 4 fully supervised and output circuits for use on Desigo Fire Safety Modular Desigo fire alarm control panels FACPs ZIC 4A supplies four 4 B or Class A output circuits power to 3.0 Amps maximum per circuit Each circuit can be independently for use with listed audible or visual notification appliances listed speakers municipal tie boxes leased lines or as releasing circuits ZIC 4A can send audio to additional speaker zones the Model EBA2004 A1 booster amplifier ZIC 4A plugs into one 1 slot in the Model CC 5 or Model CC 2 Card Cage has on board LEDs for system status and troubleshooting Indication of power internal operation and ground fault conditions are provided as as indication of circuit activation or Trouble conditions system status conditions are also reported to each Desigo Fire Safety Modular Operator Interface OI Each circuit or output may be controlled with system logic programming via custom configurable tool Zeus D or manually using the Desigo Fire Safety Modular panel on the OI control may also be time based Each circuit or can be manually Armed or Disarmed via the OI keypad any circuit or output has been Disarmed the OI display will indicate the circuit or output and the System Disable LED will illuminate until circuit or output has been returned to the condition Model ZIC 4A can also be manually energized or de energized when in the Disarmed via the OI ZIC 4A contains a microprocessor which allows outputs to function in a degrade mode if the main Desigo Fire Safety Modular panel processor or local network communication link has failed In a degrade Model ZIC 4A will respond to an Alarm or Trouble from intelligent addressable initiating device or conventional initiating device connected in the same local enclosure Data Sheet 7315 Model Product Overview continued NAC Zone Each of the four 4 circuits on Model ZIC 4A can be configured for use as a standard appliance circuit NAC The NAC output can be used as a steady strobe or zone coded output Available coding includes ANSI Temporal March 120 pulse per minute PPM March Time 60 PPM March Time 30 PPM Canadian 30 PPM Canadian Two stage 120 PPM and custom coding Zone Zone Tie Line Follower may be programmed through logic to transmit up to three 3 different signal depending on event priority For instance the same circuit can be programmed to the ANSI Temporal pattern for evacuation March Time 120 PPM for tornado and a custom code for recall of the four 4 circuits on Model ZIC 4A can be configured for use as a standard circuit in single or dual channel systems Model ZIC 4A can be used with the ZAM 180 bulk amplifier or Model ZAC 40 amplifier card Each circuit on Model is limited to 96 Watts per zone of the four 4 circuits on Model ZIC 4A can be configured for use as a releasing This circuit can be used to release Sinorix 227 or 1230 agents For proper of a releasing circuit the Model REL EOL module must be used Model REL can use power directly from the Desigo Fire Safety Modular system No external power supply is required of the four 4 circuits on Model ZIC 4A can be configured so that it can be to and activate a municipal city tie box The circuit meets the requirement of leased line module Model LLM 1 is required for this feature before box be of the four 4 circuits on Model ZIC 4A can be configured for connection to a leased The circuits can be programmed to transmit Alarm Supervisory or Trouble signals leased line module Model LLM 1 is required for this feature of the four 4 circuits on Model ZIC 4A can be configured as a NAC that can follow input from another NAC in an external FACP Circuit 1 on a Model ZIC 4A card within a Fire Safety Modular panel system enclosure can be configured as the Bell Follower and is connected to the external NAC other ZIC 4A circuit in that enclosure can be configured to follow the state of the Bell Follower This feature can be used to synchronize coded or ANSI Temporal for audible sounds with another FACP Ratings Controls and Indicators switch Model ZIC 4A card only LED the power is applied to Model ZIC 4A LED Alights when the card microprocessor has failed LED when the CAN communication and Model ZIC 4A is in degrade mode LED when the HNET communication and Model ZIC 4A is in degrade mode LED LEDs LEDs the detection of a ground fault either negative or positive on the wiring of Model ZIC 4A to indicate the zone has been either automatically or manually is one 1 LED for each zone the presence of a Trouble condition an open circuit or a short circuit on the There is one 1 LED for each zone Back Plane or External Current Draw Current Draw Terminal Current Draw Plane Current Draw Note below Device Current 24V current is dependent on the wiring type usage of each ZICCkt setting for Model ZIC 4A table found in the left hand column of the next contains the required current draws for the type and usage of each zone Technologies Division and Indicators Current Requirement ZIC 4A standby current 89mA Current A for Ordering TYPE Indicating Card End of Line Releasing Module Temperature and Humidity Range ZIC 4A is UL ULC Listed for indoor locations within a temperature range of 49 2 to 32 3 0 2 humidity of 93 2 a a temperature of 90 3 32 2 Usage Used Sync Unsync Tie USA Tie Canada Zone Line Alarm Line Trouble Line
