Siemens ZIC-8B Zone Indicating Card, Installation Instructions

Installation Instructions ZIC 8B Indicating Card FAIL FAIL FAIL FAULT 1 ACTIVE 2 ACTIVE 3 ACTIVE 4 ACTIVE 5 ACTIVE 6 ACTIVE 7 ACTIVE 8 ACTIVE Model ZIC 8B from Siemens Industry Inc is a zone card that provides notification appliance circuits for FireFinder XLS Desigo Fire Safety Modular Cerberus PRO system It has 8 outputs that can be configured as B only for control of audible and visual notification such as horns speakers bells strobes etc zone can be configured independently for different as programmed in the Zeus tool and can be controlled by program logic or manually using the PMI XLS FCM2041 U2 Desigo Fire Safety Modu FCM2041 U3 Cerberus PRO Modular Installation of a Zone Indicating Card on the ZIC 8B gives it two audio capability ZIC 8B supports synchronized and non synchronized This selection is available in the Zeus tool under the properties for each ZIC 8B circuit Synchronization across ZIC 8B cards is automatic as a part of the FireFinder Fire Safety Modular Cerberus PRO Modular characteristics Refer to document P N 315 096363 a list of strobes that support synchronization B circuit configuration can be configured independently Note on Restrictions page 2 have independent input source for 2 outputs input voltage supervision per input DC only output supervision self restoring power limiting signal synchronization capability level Ground Fault detection H Net protocol Uploadable firmware update to pass through up to 2A per output circuit 1 Zone Indicating Card features are as follows 315 048670 11 Inc Inc Inc Industry Inc Inc TTTTTececececechnologies Di Di Di Division Di zone input supplies power to two adjacent zone outputs as follows Input Zone Output and 2 and 4 and 6 and 8 associated output zones must have the same usage Each output must not greater than 2A 24 VDC During system test be sure to activate each zone pair to ensure that the maximum zone input current is not exceeded any of the ZIC 8B output circuits are used for speakers the following rules apply output circuits are available in two groups 1 4 and 5 8 Either output group can be used for speakers or NACs Each output circuit in an output group must have the same usage Unused output circuits must not be configured in Zeus Zone inputs 1 2 feed output circuits 1 4 Zone inputs 3 4 feed output circuits 5 8 ZIC 8B contains eight Class B circuits Each circuit is rated at 2A at 24VDC and an input connected to the power source and an output where the NAC devices connected The zone inputs are isolated from one another and are supervised for presence of power This allows the use of different power sources with different references The zone output is supervised for open and short circuit condi while the zone is inactive and allows different combinations of output configura standard NAC speakers etc per card Each ZIC 8B card occupies any one slot in the CC 5 CC 2 cardcage The ZIC 8B also has the capability to detect fault on its zone output as indicated by a diagnostic LED See Note above and Indicators front panel of the ZIC 8B contains one reset switch twenty one LEDs and three address switches as shown in Figure 1 reset switch is located on the top of the front panel Pushing the reset switch the ZIC 8B operation LEDs follow the reset switch and their functions are defined as follows FAIL FAIL FAIL ON When illuminated indi that power for the ZIC 8B is to the card OFF When illuminated indicates the card microprocessor has failed OFF When illuminated indicates the CAN communication with the has terminated and the card goes degrade mode applicable only when resides in a CAN network NOT USED FireFinder XLS Desigo Fire Safety PRO Modular OFF When illuminated indi that the HNET communication with ZIC 8B has terminated and the card into degrade mode applicable only card resides in the HNET network Industry Inc Technologies Division 315 048670 11 FAULT 1 ACTIVE 2 ACTIVE 3 ACTIVE 4 ACTIVE 5 ACTIVE 6 ACTIVE 7 ACTIVE OFF When illuminated indi that the ZIC 8B has detected either negative or positive ground fault on its wiring OFF When illuminated indi that Zone 1 is active OFF When illuminated indi that the ZIC 8B has detected a on Zone 1 open circuit or short or Zone 1 is disarmed OFF When illuminated indi that Zone 2 is active OFF When illuminated indi that the ZIC 8B has detected a on Zone 2 open circuit or short or Zone 2 is disarmed OFF When illuminated indi that Zone 3 is active OFF When illuminated indi that the ZIC 8B has detected a on Zone 3 open circuit or short or Zone 3 is disarmed OFF When illuminated indi that Zone 4 is active OFF When illuminated indi that the ZIC 8B has detected a on Zone 4 open circuit or short or Zone 4 is disarmed OFF When illuminated indi that Zone 5 is active OFF When illuminated indi that the ZIC 8B has detected a on Zone 5 open circuit or short or Zone 5 is disarmed OFF When illuminated indi that Zone 6 is active OFF When illuminated indi that the ZIC 8B has detected a on Zone 6 open circuit or short or Zone 6 is disarmed OFF When illuminated indi that Zone 7 is active OFF When illuminated indi that the ZIC 8B has detected a on Zone 7 open circuit or short or Zone 7 is disarmed Industry Inc Technologies Division 315 048670 11 8 ACTIVE OFF When illuminated indi that Zone 8 is active OFF When illuminated indi that the ZIC 8B has detected a on Zone 8 open circuit or short or Zone 8 is disarmed rotary dial switches at the bottom of the front panel are used to set the HNET address of the ZIC 8B Zones ZIC 8B output zones can be configured as 25V or 70V speaker zones or for the standard NAC Zone usages Synchronized or Unsynchronized Coding Code Temporal 4 when used with Audible Base SBGA 34 Time 120 Time 60 Time 30 2 stage 30 2 stage 120 Horn Strobe Options order to perform its intended operation the ZIC 8B card must be programmed the Zeus Programming Tool The ZIC 8B card and its Out Ckt properties must set prior to normal operation the Zeus Programming Tool highlight the selected ZIC 8B card in the Physical and open the Detail View Properties to modify and or define the following card properties Address address must match the address in ZIC 8B hardware Language Custom Message message associated with ZIC 8B card Language Custom Message message associated with ZIC 8B in an alternate language CARD 24V Power Source back plane or screw termnals Card Installed if ZIC 2C card is installed ZIC 8B card is subdivided into eight output circuits that can be programmed In the Zeus Programming Tool highlight the selected ZIC 8B Output in the Physical View and open the Detail View Properties to modify and or the following ZIC 8B output circuit properties Address preset address of ZIC card output Language Custom Message message associated with the ZIC 8B circuit Industry Inc Technologies Division 315 048670 11 Language Custom Message Usage Circuit Usage Mode Alarm Activation Option T
